8
Data Sheet
DS-VA-1350E-eng
March, 2008
Models 1350E and 1355E
Table 6 Ordering Information and Model Code Continued
VALVE TYPE
A VALVE PLUG
B BRASS - LOW FLOW
C BRASS - MEDIUM FLOW
D BRASS - HIGH FLOW
E 316 STAINLESS STEEL - LOW FLOW
F 316 STAINLESS STEEL - MEDIUM FLOW
G 316 STAINLESS STEEL - HIGH FLOW
H NRS-BRASS #1
J NRS-BRASS #2
K NRS-BRASS #3
L NRS-BRASS #4
M NRS-BRASS #5
N NRS-BRASS #6
P NRS - 316 STAINLESS STEEL #1
Q NRS - 316 STAINLESS STEEL #2
R NRS - 316 STAINLESS STEEL #3
S NRS - 316 STAINLESS STEEL #4
T NRS - 316 STAINLESS STEEL #5
U NRS - 316 STAINLESS STEEL #6
V TO INTEGRALLY MOUNTED FLOW CONTROLLER
W STANDARD VALVE CAVITY - NO VALVE ASSEMBLY OR PLUG
X NO VALVE CAVITY (MUST USE CODE 9 BELOW FOR VALVE CAVITY LOCATION)
VALVE CAVITY LOCATION CONNECTION ORIENTATION
1 INLET IN-BACK, OUT-BACK (STANDARD)
2 INLET IN-BACK, OUT-FRONT
3 INLET IN-FRONT, OUT-BACK
4 INLET IN-FRONT, OUT-FRONT
5 OUTLET IN-BACK, OUT-BACK (STANDARD)
6 OUTLET IN-BACK, OUT-FRONT
7 OUTLET IN-FRONT, OUT-BACK
8 OUTLET IN-FRONT, OUT-FRONT
9 NONE (INLET SIDE) USE WITH CODE X ABOVE IN-BACK, OUT-BACK
ACCESSORIES-1,2, OR 3 DIGIT FIELD
A NONE
B ALUMINUM FLUSH MOUNTING BEZEL
C FLUSH PANEL MOUNTING FOR KYNAR METERS
E TRIPOD BASE WITHOUT SPIRIT LEVEL
J DEGREASE FOR OXYGEN SERVICE
L STAINLESS STEEL SIDE PLATES
M STAINLESS STEEL SPRING FLOAT STOPS
N NIST CERTIFICATION INCLUDES CALIBRATION AND SCALE CHECK (10%, 1350; 5%, 135
Q NO BROOKS IDENTIFICATION
Example: 1350EJB9 AAA1A
