NRSTM Needle Control Valves Models 8503 and 8504 - Brooks Instrument - #4

Text version of the page

Table 3 Ordering Information and Model Code MODEL NEEDLE VALVES 8503D NRS, ANGLE PATTERN 8504D NRS, IN-LINE PATTERN 8513D NRS, ANGLE PATTERN WITH DIGITAL HANDLE 8514D NRS, IN-LINE PATTERN WITH DIGITAL HANDLE || CODE MATERIAL OF CONSTRUCTION | 1 BRASS | 2 316 STAINLESS STEEL | | CODE NEEDLE AND ORIFICE SIZE | | A SIZE 1 | | B SIZE 2 | | C SIZE 3 | | D SIZE 4 | | E SIZE 5 | | F SIZE 6 | | | CODE OPERATING PRESSURE | | | 4 STANDARD 600 PSI BRASS / 1000 PSI STAINLESS STEEL | | | | CODE O-RING MATERIAL | | | | A BUNA-N | | | | B VITON | | | | | CODE INLET AND OUTLET CONNECTIONS SIZE AND TYPE | | | | | 1A 1/8" NPT INTEGRAL | | | | | 2B 1/8" COMPRESSION | | | | | 3C 1/4" NPT | | | | | 4D 1/4" COMPRESSION | | | | | 5E 1/4" I.D. HOSE | | | | | | 8504D 1 C 4 A 1A TYPICAL MODEL CODE BROOKS LOCAL AND WORLDWIDE SUPPORT .. Brooks Instrument provides sales and service facilities around the world. .. Calibration facilities are available in locally based sales and service offices. Certified by our local Weights and Measures Authorities and traceable to the relevant international standards. START-UP SERVICE AND IN-SITU CALIBRATION .. Brooks Instrument can provide start-up service prior to operation when required, if necessary under in-situ conditions, and the results will be traceable to the relevant international quality standards. CUSTOMER SEMINARS AND TRAINING .. Brooks® can provide customer seminars and dedicated training to engineers, end users and maintenance persons. HELP DESK In case you need technical assistance: Americas 1-888-554-FLOW Europe +(31) 318 549 290 Within Netherlands 0318 549 290 Asia +011-81-3-5633-7100 Due to Brooks Instrument's commitment to continuous improvement of our products, all specifications are subject to change without notice.
