4 Specifications Subject to Change Without Notice Table 3 Ordering Information and Model Code TRADEMARKS Brooks .......................................................... Brooks Instrument, LLC Brooks-Line IV ............................................. Brooks Instrument, LLC LFC ............................................................... Brooks Instrument, LLC Teflon ................................................. E.I. DuPont de Nemours & Co. Viton ............................................... DuPont Performance Elastomers HELP DESK In case you need technical assistance: Americas 1-888-554-FLOW Europe +(31) 318 549 290 Within Netherlands 0318 549 290 Asia +011-81-3-5633-7100 BASE MODEL NU DESCRIPTION 1510D 65 MM SCALE WITH HORIZONTAL CONNECTIONS CODE TUBE, SCALE AND FLOAT SEE TABLE 1 SEE TABLE 2 CODE TUBE PACKING AND O-RING MATERIAL A VITON AND VITON B BUNA-N AND BUNA-N C NO PACKING AND VITON O-RINGS D NO PACKING AND BUNA-N O-RINGS E EPR AND EPR CODE CONNECTION SIZE 1 1/4" NPT - BROOKS LOGO - STANDARD CONNECTION LENGTH 3 1/4" NPT - BROOKS LOGO - DOWNPORT (4.59" CONNECTION LENGTH) A 1/4" NPT - NO LOGO - STANDARD CONNECTION LENGTH C 1/4" NPT - NO LOGO - DOWNPORT (4.59" CONNECTION LENGTH) CODE VALVE CONFIGURATION A NO VALVE, PLUG ON INLET B LOW FLOW VALVE ON INLET C LOW FLOW VALVE ON OUTLET D MEDIUM FLOW VALVE ON INLET E MEDIUM FLOW VALVE ON OUTLET F HIGH FLOW VALVE ON INLET G HIGH FLOW VALVE ON OUTLET H TO STAINLESS STEEL FLOW CONTROLLER (SEE NOTE) J TO BRASS FLOW CONTROLLER (SEE NOTE) K STANDARD VALVE CAVITY - NO VALVE ASSY OR PLUG Example: 1510DAB4A1A FLOW CONTROLLER MUST BE A SECOND LINE ITEM ON CUSTOMER ORDER. xxx
