Applications The UCM-97 Communicator is highly versatile, and as such can beused in many modern communication applications for:

GPRS Communicator

? Wireless networking of industrial HW using Internet technology ? Wireless communication to remote sites using VPN

UCM-97

? Wireless communication to a remote Ethernet network(Router facilities)

INTRODUCTION

? ? Various Wireless Client-Server networking solutionsKey applications includes: Replacement of Leased Line technology Features ? UCM-97 Communicator Remote monitoring ? Advanced metering applications The UCM-97 GPRS Communicator is a single component, complete and compact modem device that allows you to add “Internet ready” wireless communication to your application. Housed in a robust aluminium enclosure the UCM-97 is designed for use in industrial environments.The UCM-97 has integrated inteliggence which take care of all theGPRS login options for you. It works directly like a stand-alone unit and do the hole GPRS login procedure automaticly. All you has to provide is a SIM card with an enabled GPRS account and enter the specific AccessPoint Name (APN). When connected your UCM-97 is ready as a wireless network connection transparent to the physical Ethernet interface.By using the GPRS Communicator any serial device can be directlyconnected to the IP world via the GPRS network. An internal Internet gateway converts your serial data into IP frames offering an easy configurable communication channel without requirements of special knowledge of General Packet Radio Services (GPRS) or PPP protocol handling.Two communication ports, one serial RS232 or RS485 and oneEthernet, are provided with the GPRS Communicator. These can be used to collect data from the equipment being monitored or simply as a transparent gateway.The UCM-97 GPRS Communicator includes a complete Web-Serverfor configuration, maintenance and customised purposes. From a standard Web Browser such as MS Internet Explorer you configure the different communication parameters, uploads new facilities or even browses your own dynamic Web-pages stored in the module. The full networking functionality makes it possible to have as much as 10 clients concurrently browsing the same module. The UCM-97 GPRS Communicator in the basic version offers: ? Traffic light control ? GPRS class 10 and GSM Dual band 900/1800 MHz commu-nication facilities ? Rail crossing Monitoring ? Dynamic signs and information displays ? Extended watchdog functions for both modem and controllerto provide maximum GPRS connection uptime. ? Automatic login to predifend Server function which enableconnection in GPRS applications with dynamic assigned IP addresses (ReverseGateway). ? Built-in Web-Server used for configuration, maintenance andopen for customisation of your own web pages ? Multi-networking protocol support; UDP, PPP, TCP, HTTP,FTP, SMTP, Telnet, MIME ? Seriel to TCP/IP protocol industrial converter options; ModbusRTU toModbusTCP. ? Interfaces: Ethernet 10BASE-T and RS232 V24 or RS485 ? 12-24VDC power supply input ? Industrial mounting on 35 mm DIN railAdditional factory fit options are available for other applications: ? Built-in AVR 8-bit application controller (ATMEGA type) withserial RS232 interface to handle application specific control parameters or communication driver implementation. ? Email and SMS support ? I/O expansion bus for connecting I/O modules directlyto the GPRS Modem / Communicator. ? Unit with integrated I/O for alarms etc.

TECHNICAL DESCRIPTION

The UCM-97 GPRS Communicator is ready to integrate with existingapplications. The UCM-97 has a standard serial RS232 port that can be configured as a tunnel, enabling transparent serial communication via GPRS, PPP and TCP/IP at a maximum speed according to GPRS class 10. Alternatively the serial RS232 port can be used by an application programme to gain access to equipment, if a driver is written for the specific communication protocol. Optionally the UCM-97 GPRS Communicator can be delivered with an 8-Bit AVR application controller. The purpose of this additional control- ler is to give users a very flexible application platform programmed by you or by us. Using a Browser as interface you are free to programme the AVR controller. Also users will have direct Telnet access to the application controller enabling easy debugging or data manipulation using Java applets.
Brodersen Controls A/S * Industrivej 3 * DK-4000 Roskilde * Denmark * Tel (+45) 4674 0000 * Fax (+45) 4675 7336 40150 120 / 27.04

1
