D D a a t t a a a a n n d d D D i i m m e e n n s s i i o o n n s s
Industrial slide Rings & Segments “R” series slide rings are manufactured from high quality steel, zone hardened on the V edges and preci-sion ground all over with datum register faces, provided both internally and externally, for ease of location. Gear drive options are available with teeth machined into either the internal or external register face. The number of teeth on the standard external option is divisible by 12 in order to provide maximum choice of pinion size for exact ratio requirements. Customers may also choose the tapped hole option “N” which enables the slide ring to be bolted from below. 12 © Bishop-Wisecarver Corporation 2008. All rights reserved.
