| specifically designed for such application. This will require the counterbored screw fixing option to be specified for the slide in order to provide a flush running surface for the belt. The counterbored screw fixing option will also be required where there is insufficient room between slide and carriage plate for screw heads (possible in "mix and match" situations or where customer's own flat carriage plates are used in conjunction with slimline bearings). For customers requiring a belt driven system complete with end pulley units, Bishop-Wisecarver recommends their standard range of Driven Linear Systems, details of which may be found in the comprehensive HepcoMotion DLS catalog. Also included in the DLS catalog are compatible motors, gearboxes and switching equipment, all of which may be suitable for customers carrying out their own designs using the slide beam. | ||||||||||||||||||||||||||||||||||||||||||||
| See Application Examples on page 10 | ||||||||||||||||||||||||||||||||||||||||||||
| L *1,2,3 | ||||||||||||||||||||||||||||||||||||||||||||
| Weight kg/m | ||||||||||||||||||||||||||||||||||||||||||||
| L Max *1, 2, 3 | Part Number | |||||||||||||||||||||||||||||||||||||||||||
| Light Beam | ||||||||||||||||||||||||||||||||||||||||||||
| Standard C/Bored | Std Beam | |||||||||||||||||||||||||||||||||||||||||||
| 3.3 10.5 M6 M5 5.5 8000 DFC3S DFC3L 75 48 M6 6 3.3~M0.5"1 M6 ~M5 5.5~r8000~nDFC3S~rDFC3l- 75 48 M6 6.5 3.3 10.5 M6 M6 5.5 8000 DFC4S DFC4L 100 65 M8 10 4.4~Tl4n M8 ~M6 5.5n~8000~1~DFC4S~rDFC4L 100 65 M8 11 4.4 14 M8 M6 5.5 8000 DFC4S DFC4L 100 65 M8 11.5 | 4.3 4.7 | SB S 35... SB S 50... SB M 44... SB M 60... SB M 76... | ||||||||||||||||||||||||||||||||||||||||||
| Ordering Details | ||||||||||||||||||||||||||||||||||||||||||||
| SBS35 L1346 P1 (L) (C) (X) (C33) (D53) | ||||||||||||||||||||||||||||||||||||||||||||
| Part Number- Beam Length 'L' = 1346 mm _ Precision grade: options are PI, P2 & P3 L - Lightweight beam option_ (leave blank if not required) | -Tailored values of C & D dimensions in mm - Leave blank if standard*2 End cover option (leave blank if not required) _C - Counterbored screw fixing option (leave blank if not required) | |||||||||||||||||||||||||||||||||||||||||||
| X - | ||||||||||||||||||||||||||||||||||||||||||||
| Ancillary Items: See drawing for the part numbers relating to T nuts*5, T slot cover*6 and fixing clamps. | ||||||||||||||||||||||||||||||||||||||||||||
