Clamping Range : ø0.45 - ø8.05 ø10 ultra small dia. to avoid interference. High precision is maintained by combination with MEGA NEW BABY CHUCK. L Collet Model CYLINDRICAL SHANK Spare Parts MEGA WRENCH MICRO COLLET PROTECTIVE CASE TAPER CLEANER MEGA MICRO CHUCK SET Including convenient storage case. Set model

Coolant-through hole Clamping Range : ø0.25 - ø20 Adjusting Screw (Optional) Adjusting Screw (Optional) 1. MEGA NUT is included. 2. "H" indicates the adjustment length with an Adjusting Screw. 3. ST LOCK is recommended to mount / release a cutting tool. MEGA WRENCH NBC COLLET G3 For ENDMILL COLLET G7 MEGA NEW BABY CHUCK MEGA 6N MEGA 8N MEGA10N MEGA13N MEGA16N MEGA20N MEGA PERFECT SEAL ADJUSTING SCREW Rubber B L G Spare Parts CYLINDRICAL SHANK Cylindrical shank models offer flexible solutions against possible interference in combination with MEGA DOUBLE POWER CHUCK.

Clamping Range : ø0.25 - ø20 Avoids interference when used in combination with BIG NEW Hi-POWER MILLING CHUCK. L Adjusting Screw (Optional) L Adjusting Screw (Optional) 1. NEW BABY NUT is included. 2. Models marked with are not equipped with a hole through for coolant.

Coolant-through hole Reliable solution for deep and narrow access having slim head and solid carbide shank. Standard Type Model CYLINDRICAL SHANK Remarks : Collet and Wrench are not included. NEW Hi-POWER MILLING CHUCK NEW Hi-POWER MILLING CHUCK ensures high accuracy, high rigidity and powerful gripping force for Carbide Cylindrical Shank New Baby Chuck. Spindle Speed : 1,000 min-1 Cutting Feed : 0.1mm/rev. Cutting Depth : 0.5mm Cutter : 5mm Solid Carbide End Mill Workpiece : Cast Iron G025 (DIN) FC25 (JIS) NBC COLLET G3 For ENDMILL COLLET G7 BABY PERFECT SEAL Spare Parts

Coolant-through hole SUPER SLIM Type Slim design avoids interference with the side wall and draft of the mold. CYLINDRICAL SHANK 1. Use carbide cutter within a tolerance of h6. 2. Use carbide cutter within a tolerance of h5. Please refer to the operation manual of heating / cooling equipment, as some equipments may not be compatible. Max. insertion length: H Min. Clamping Length E Wiper Cleaner is recommended to clean the cl

SLIM Type Max. insertion length: H Min. Clamping Length E 1. Use carbide cutter within a tolerance of h6. Please refer to the operation manual of heating / cooling equipment, as some equipments may not be compatible. Wiper Cleaner is recommended to clean the clamping bore. G 19 CYLINDRICAL SHANK

Coolant-through hole SHRINK CHUCK STANDARD Type Max. insertion length: H Min. Clamping Length E 1. Use carbide cutter within a tolerance of h6. 2. Use carbide cutter within a tolerance of h5. Wiper Cleaner is recommended to clean the clamping bore. G 19 Please refer to the operation manual of heating / cooling equipment, as some equipments may not be compatible. Max. insertion length: H Min. Clamping Length E Max. insertion length: H Min. Clamping Length E Air-bleeding hole CYLINDRICAL SHANK 1. Designed for center through coolant application when used with coolant through cutting tools.

Tapping Holder MEGA SYNCHRO Coolant-through hole 1. Tap Holder and wrench are ordered separately. Rigid tapping function is required on the machine tool. Side Lock Holder model TSL is recommended as a basic holder. For SIDE LOCK HOLDER A Tapping Range for DIN & ISO Standard MGT Size ISO Standard ISO529 ISO2284 M3-M5 M6,M8,M12 1/8 M10-M20 1/4-3/8 For detail of TAP HOLDER A 1. 12mm common spanner is also required to hold the body when clamping/unclamping the tap. MICRO COLLET For MGT3 90 Micro Collet NBC4S- 1. Nut is included. Wrench and collet are ordered separately. 2.12mm common spanner is also...

Other products with cylindrical shank ACCESSORIES MASURING TOOLS Environment improvement tool Touch probe & edge finder Position detecting tool POINT MASTER Full automation of swarf and coolant removal by means of wind pressure. Touch sensors provided with high precision stroke and interchangeable stylus for measuring different applications. POINT CENTER ACCU CENTER Precise detection of wokpiece position in X & Y axes. Simple and precise edge finder offering repeatability within 3µm. CUTTING TOOLS Indexable Insert Endmill Ultra high feed chamfer mill Extensive chamfering range C-CUTTER Universal...
