Ease of mounting

The unit can be mounted from the ceiling in any convenient location in thespace, as the adjustable nozzles ensure delivery of the heat to the required areas. A suspension set, which is available as an accessory, or "traditional” standard threaded rods can be used to hang the units. The suspension set makes moun- ting considerably easier and faster.

Models

The Biddle air heater is available in two models. The range comprises of the NOZ 25 and the NOZ 50. If lower temperature water ranges are used, special higher-capacity heating batteries can be mounted in the air heaters. A wide range of accessories, such as a suspension set, and control and switching gear, is also available from Biddle.

Quick selection

For a quick selection, refer to the data from the table below. This data is based on a water range of 90/70 ºC, an intake-air temperature of 15 ºC, and a room heat loss of 20 Watt/m * For situations where comfort require- ments are high, it is recommended to use more units of lower heating capacity. If comfort requirements are lower, fewer units of high heating capacity will do. Technical data available on request. Subject to change.
Type HeatingMounting Area ofApplication* capacityheightInfluence NOZ 2525 kW2.8 - 8.5 m400 - 100 m 2 - low rooms- higher comfort requirementsNOZ 5050 kW3.5 - 14 m800 - 200 m 2 - high rooms- lower comfort requirements 3 .

Selection advice

Of course, you can rely on Biddle for detailed information and technical advice at any time. If you have any queries about improvement or control of your total indoor climate, Biddle will be pleased to help you. After all, “climate work” is our profession.

Quality

Biddle is your guarantee for excellent service, world-class quality, and serving the needs of its clients by resolving their “climate” problems. In addition to that, Biddle considers technical innovation as one of its major objectives and has successfully exploited its innovative capabilities in creating this air heater. Biddle bv P.O. Box 15 NL-9288 ZG Kootstertille The Netherlands tel.+31512 33 55 55 fax+31 512 33 55 54 e-mail export@biddle.nl internet www.biddle.info
NOZ-EN-2004-10-1000?247744
