For vacuum packing or gas flushing p ackin g of sensitive p roducts.

A

Application

This vacuum packing process enables to keep sensitive products all their initial qualities such as : colour, taste, smell,….The multilayer materials used for the bags must be efficient and complementary to improve and have the maximum protection of the products (against airmoisture, gas, U.V. rays,…).

B

Benefits

- Quality of vacuum, gas flushing and sealing - Easy setting and using (cycles managed by Programm Logic Controller) -Easy adjustements (touch screen) and maintenance -Nice looking of the bags with trolley option - 2 sealing ways to optimize production (option)

Touch screen

Description

A – Sealing bars B – Free rolls conveyor C – Plexiglas door (2)

F

D – Watertight command panel with touch screen E – Connections plate (vacuum pump, electricity, compressed air, gas) F – Plexiglas cover

D

Different models :

? CT270 – 324S model Chamber 0,265 m
3 – packagings from 1 to 40L

C

? CT320 – 324M model Chamber 0,332 m
3 – packagings from 1 to 40 L ? CT680 – 454L model Chamber 0,681 m
3 – packagings from 1 to 60L

E

? CT1176 – 724XL model Chamber 1,176 m
3 – packagings from 1 to 200L

Useful dimensions according to model

CT270-324S CT320-324M CT680-454L CT1176-724XL

Chamber internal dimensions
(length x width x height) 1000 x 324 x 820 1250 x 324 x 820 1500 x 454 x 1000 1250 x 724 x 1300 Useful length of sealing in mm
(length of sealing x height of sealing) 780 x 10 1040 x 10 1290 x 10 1040 x 10 Useful height in mm
(from the high level of the rolls to the sealing axle) 635 635 815 1150
Document non contractuel - Gamme méca/Cuve Tunnel A.doc
