Text version of the page
Lamps
LED lamps 2) 10 years lifetime
Socket BA9s
Power
Pack
Weight
Lamp voltage
consumption
Type
pes.
kg/pc.
ifetime
20-30V AC/DC
17mA / 0,4W
for
red lens caps
B3
L24 RTB
10
0,005
20-30V AC/DC
17mA / 0,4W
for
green lens caps
B3
L24 GNB
10
0,005
20-30V AC/DC
17mA / 0,4W
for
yellow lens caps
B3
L24 GEB
10
0,005
20-30V AC/DC
17mA / 0,4W
for
blue lens caps
B3
L24 BLB
10
0,005
20-30V AC/DC
17mA / 0,4W
for
white lens caps
B3-
L24 WSB
10
0,005
90-120V AC/DC
7mA / 0,8W
for
red lens caps
B3
L110 RTB
10
0,005
90-120V AC/DC
7mA / 0,8W
for
green lens caps
B3
L110 GNB
10
0,005
90-120V AC/DC
7mA / 0,8W
for
yellow lens caps
B3
L110 GEB
10
0,005
90-120V AC/DC
7mA / 0,8W
for
blue lens caps
B3
L110 BLB
10
0,005
90-120V AC/DC
7mA / 0,8W
for
white lens caps
B3-
L110 WSB
10
0,005
200-250V AC/DC
4mA / 0,9W
for
red lens caps
B3
L230 RTB
10
0,005
200-250V AC/DC
4mA / 0,9W
for
green lens caps
B3
L230 GNB
10
0,005
200-250V AC/DC
4mA / 0,9W
for
yellow lens caps
B3
L230 GEB
10
0,005
200-250V AC/DC
4mA / 0,9W
for
blue lens caps
B3
L230 BLB
10
0,005
200-250V AC/DC
4mA / 0,9W
for
white lens caps
B3-
L230 WSB
10
0,005
12V
1,2W
for
all lens caps
B4
G12
50
0,005
24V
1,2W
for
all lens caps
B4
G24
50
0,005
42V
1,2W
for
all lens caps
B4
G42
50
0,005
48V
1,2W
for
all lens caps
B4
G48
50
0,005
60V
1,2W
for
all lens caps
B4
G60
50
0,005
110/120V 1'
1,5/1,8W
for
all lens caps
B4
G130
50
0,005
220-250V AC 220-250V AC
0,3W 0,3W
for clear, red, yellow lens caps for green, blue lens caps
B4-GL230K B4-GL230G
100 100
0,005 0,005
ft
Filament lamps
Glow-discharge lamps
Accessories
VPE
Gewicht
Type
Stk.
kg/Stk.
Wrench
for mounting of actuators
J7049
1
0,018
and lens caps B(S)3..
Marking plate
for marking of contact blocks B3T.
P672-1
10
0,001
and lamp holders B3F
Lamp Installer
used to install or replace lamps BA9s
B4-7408
1
0,010
Spare Key
for B(S)3SA.. and BS3P44S3, Ronis R455
B4-R455
1
0,007
for b(s)3SB.. , Ronis R786
B4-R786
1
0,007
Hole Plug
black, for fixing holes 022,5mm
B3-DU SW
10
0,007
grey
B3-DU GR
10
0,007
Sealing Cover
ambient temp. 0o - +50o C 3)
P279-1
1
0,003
protection
petrol-resistant 3)
against coarse
P279-3
1
0,003
contamination
ambient temp. -25o - +55o C
for double push buttons, petrol-resistant
P279-DT
1
0,003
ambient temp. -25o - +55o C
Protection cover
against unintentional manupulation
Thickness 1mm yellow
B3-SK GE
1
0,04
Protection ring
Thickness 1mm grey
B3-SK GR
1
0,04
against unintentional manupulation
with thread
has to be mounted instead black
P921-1
1
0,012
of the existing ring chrome
P921-2
1
0,012
alu
P921-3
1) Voltage marking 130V / 2W max. rated voltage 120V /1,8W 2) suitable for B3FT lamp test lamp holders 3) not for B3D..R.. (maintained)
D580E
Dimensions and technical datas are all subject to change without notice
9
