Assembled Stations IP67 (IP65) .®- Typ12 For conduit entries are in top and both small sides only one knockouts for conduit hubs 020,5mm, for M20 or PG13,5 provided.

Diagram				Type		Pack Weight pcs. kg/pc.

Plastic enclosed buttons and Pilot Lights ON push button green			o 14—^—13 ® 22—J^21 X2—(8)—X1		BG10 GN	0,135
	OFF push button red				BG10 RT	0,135
	Pilot light green Pilot light red				BG01 GN BG01 RT	0,135 0,135

Key operated 0 - I ^1J lock Ronis R455 60° maintained			14-•"—13		BG10SAR 0	0,165

Key operated I - 0 - II ¹⁾ lock Ronis R455 60° maintained					BG10SARR 0	0,172

	2 push buttons 0 - I		® o 22—1^21 14—¿"—13 \A—2r—13 14—f-—13 I I 22—ix-21 22—4j^21		BG20	0,200
	2 push buttons <- -—				BG20PF	0,200

	3 push buttons <- 0 —		®		BG30PF	0,283
	14—f—13 22—Jj^21 14—f—13 I ^ I 22—Jj— 21 22—Jj— 21
	3 push buttons I - 0		BG30 T T T 14—f—13 22—Jj^21 14—f—13 I ^ I 22—Jj— 21 22—Jj— 21			0,283
	2 push buttons 0 - I with pilot light green		BG21 GN X2—<g>— X1 22—1^—21 14—J"—13			0,270
	Foot and palm button mushroom 070mm				BG10P14P GR	0,187
			14—f—13 I 22—Jj— 21

Plastic enclosed EMERGENCY STOP buttons

o	EMERGENCY STOP button head 040mm unlock by turning				BG10P34-11	0,145

	EMERGENCY STOP mushroom button 040mm according to EN418 unlock by pull EMERGENCY STOP key operated button 040mm according to EN418 unlock by key EMERGENCY STOP mushroom button 070mm unlock by turning				BG10P44-11	0,145

					BG10P44S3-11	0,178
					BG10P34P-11
						0,187


1) IP65

	D580E	Dimensions and technical datas are all subject to change without notice				19
