Emergency-Stop-Main Switches, Base Mounting with Door Clutch, Padlock Device for Four-Hole Mounting Depth X is adjustable (delivered with T

max

see page 8), IP66

max.AC21AC23Plate Type PackWeigthpadlocks690V3x400Vpcs. kg/pcs

3-pole , padlock device SV4(34)

20A 7,5kW 64
1 )LTS20 VHN4 A310,2025A 10kW 64
1 )LTS25 VHN4 A310,2032A 12,5kW 64
1 )LTS32 VHN4 A310,2040A 16kW 64
1 )LTS40 VHN4 A310,2063A 22kW 64
1 )LTS63 VHN4 A31 0,2480A 22kW 64
1 )LTS80 VHN4 A310,2485A 30kW 64
1 )LTS85 VHN4 A310,40100A 37kW 64
1 )LTS100 VHN4 A310,40125A 45kW 64
1 )LTS125 VHN4 A310,40160A 55kW 88 LT160 VHN34 T30011,38

4-pole , padlock device SV4(34)

20A 7,5kW 64
1 )LTS20 VHN4 A410,2125A 10kW 64
1 )LTS25 VHN4 A410,2132A 12,5kW 64
1 )LTS32 VHN4 A410,2140A 16kW 64
1 )LTS40 VHN4 A410,2163A 22kW 64
1 )LTS63 VHN4 A41 0,2880A 22kW 64
1 )LTS80 VHN4 A410,2885A 30kW 64
1 )LTS85 VHN4 A410,45100A 37kW 64
1 )LTS100 VHN4 A41 0,45125A 45kW 64
1 )LTS125 VHN4 A410,45160A 55kW 88 LT160 VHN34 T40011,77

6-pole, 8-pole on request Changeover Switch with Padlock Device for Base Mounting on request

Emergency-Stop-Main Switches, Base Mounting with Door Clutch for Single-Hole Mounting Depth X is not adjustable, declare depth X when ordering, IP66

4-pole , padlock device SV4

20A 7,5kW 64 LTS20 VZHN4 A4 X..10,1825A 10kW 64 LTS25 VZHN4 A4 X..10,1832A 12,5kW 64 LTS32 VZHN4 A4 X..10,1840A 16kW 64 LTS40 VZHN4 A4 X..10,1863A 22kW 64 LTS63 VZHN4 A4 X..1 0,2580A 22kW 64 LTS80 VZHN4 A4 X..10,25

3-pole, 6-pole, 8-pole on request

Dimension X

Declare depth X when ordering

TypePreference values for XLTS.. VZH.. 80, 85, 104, 129 (tolerance -3, +1,5)

Add-on modules see page 7

1)Types with padlock device 88 type suffix 88, ordering example: LTS32 VHN4 88 A3, on request
