Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:9.00pt "Arial", sans-serif; } Ratings Protection degree from front in mounted position Main Switch Emergency Stop Panel mounting Single hole mount. Base mounting 022,5mm with door coupling IP66 IP66 adjust. installation depth IP66 Type Rated current Therm. Ith open AC21 at Ue AA Ve Motor AC3 AC23 3~400V 3~400V kW A kW Plate Switch disconnector mm LTS20 20 20 690 5,5 16 7,5 48° LTS20 LTS20 EHN1 EHN4 LTS20 ZHN1 LTS20 VZVHN4 LTS20 VHN4 LTS25 25 25 690 7,5 20 10 48° LTS25 ZHN1 LTS25 VZVHN4 LTS25 VHN4 LTS32 32 32 690 11 25 12,5 48° LTS32 ZHN1 LTS32 VZVHN4 LTS32 VHN4 LTS40 40 40 690 15 32 16 48° LTS40 ZHN1 LTS40 VZVHN4 LTS40 VHN4 LTS63 63 63 690 18,5 45 22 48° LTS63 VZVHN4 LTS63 VHN4 LTS80 80 80 690 18,5 45 22 48° LTS80 VZVHN4 LTS80 VHN4 LTS85 85 85 690 22 60 30 64° LTS85 EHN4 LTS85 VZVHN4 LTS85 VHN4 LTS100 100 100 690 30 72 37 64° LTS100 EHN4 LTS100 VZVHN4 LTS100 VHN4 LTS125 125 125 690 37 85 45 64° LTS125 EHN4 LTS125 VZVHN4 LTS125 VHN4 LT160 160 160 690 45 110 55 88° LT160 EHN34 LT160 VHN34 Switch disconnector LT.. 20 - 160A Switch disconnectors are to be used as an ON-OFF-switch where a high breaking capacity with high contact pressure and in fact better short circuit behavior is necessary. These applications are: Main switches according to IEC/EN 60204 respectively VDE0113 with interlocking device, terminal protection and restrective contacts. Switch disconnectors according to IEC/EN 60947-3 and VDE 0660 part 107 with break distance for 690V. Motor switches 3-pole or 4-pole; according to IEC/EN 60947­3 respectively VDE 0660 part 107, motor switches series LT are dimensioned for switching high rated current AC3 and AC23A. Main switches and Main switches with Emergency-Stop function According to standards IEC/EN60204 or VDE0113, all electrical equip-ment of industrial machines must be equipped with a main switch. This must permit disconnection of all the electrical equipment during cleaning, maintenance and repair work, and other extended periods when it is stationary. In case of two or more main switches, an interlock system must be used. It is recommended to use a multiple-pole main switch (cam switch). Main switches have to correspond to: a) Switch disconnector according to IEC/EN 60947-3 and VDE 0660 part 107 for utilization category AC23-B or DC-23B. b) Disconnectors are selected according to thermal rated current. They must possess a contact that ensures load switching via the contac-tors (see switching program A3-10). This contact must have a sufficient AC15 switching capacity. c) The interruption capacity of the switch must equal or exceed the locked rotor current of the largest motor plus the total current of all other electrical equipment in the circuit. Requirements: Interruption of the electrical equipment, with only on and off positions clearly marked with O and I. It must be lockable in the off setting. The line terminals of the main switch must be protected according to utilization category IP2X. Colour of handle black or grey. Main switches with Emergency-Off function are additional supplied with red handles and contrasting yellow escutcheon plates. 2 Technical data are subject to change without notice OLNECIKTSJAQËR D656E
