Dimensions

Enclosures

M4 32R PFH4M4 32R PFHN4

Door-coupling rotary mechanismsMounting holes

TypeAM4 32R EH1 115149 - 210M4 32R EHN1 115149 - 210 M4 32R EH1 315149 - 410 M4 32R EHN1 315149 - 410TypeAM4 63R EH1 115194 - 255M4 63R EHN1 115194 - 255 M4 63R EH1 315194 - 455 M4 63R EHN1 315194 - 455 TypeAM4 100R EH1 115220 - 282M4 100R EHN1 115220 - 282 M4 100R EH1 315220 - 482 M4 100R EHN1 315220 - 482

Insulated 3-phase busbar system

M4 32 S..M4 32 SE 20Dimensions and technical datas are all subject to change without notice D795E
