| Benecom's quality products solutionslooon | ||||||||||||||||||||||
| 3PE№C O Embedded CPU Board | ||||||||||||||||||||||
| bem-600b | ||||||||||||||||||||||
| « m | ||||||||||||||||||||||
| Power connector 1 x 20 pins ATX power connector. Temperature Operating: 0oC~55°C Storage: -10°C ~70°C Humidity 5%~95% RH, Non-condensing Dimensions 219mm x 159mm (8.6inch x 6.3inch) EMI/EMS Meet the CE and FCC class B regulation. Other function Support USB device boot up (FDD, HDD, CD-ROM) support dual display RoHS RoHS compliant VGA connector 1 x DB-15 VGA connector supporting up to 1600 x 1200 1 x internet VGA pin head. LCD Interface 1 x LCD 30 pin header interface ( Support 24bits LVDS, Dual channel) IDE Two enhanced IDE Support up to 4 devices including UDMA133/100/66/33 Mode Connector: One 40-pin & one 44 pin pin-headers. Serial Port Four COM ports with ESD protected COM 1/2: RS232 DB-9 connector COM 3: RS232/422/485 DB-9 connector COM 4: RS-232 2x5 2.54 pitch pin-header USB Four 4 USB 2.0 port Connector: Two USB connector external / Two 2x4, 2.54 pitch pin-header internal Parallel Port One multi-mode parallel port (SPP/EPP/ECP) USB Four 4 USB 2.0 port Connector: Two USB connector external / One 2x4, 2.54 pitch pin-header internal K/B & Mouse Two 6-pin mini-DIM PS/2 K/B & mouse Connector IrDA One IrDA pin-header Digital I/O 4 digital-input / 4 digital-output | ||||||||||||||||||||||
| Intel Mobile Celeron embbeded CPU X|E SÜ£ Ar§Xr°| *!e-H0|| № Afè 7fetM 7 lé BEM A|a|x£f £|v§4 se U||£o| 0| JEEOlWe RoHS 7|£0| AH£0| *|£ÜE|d1 Cooling Fan°£ 7|é Pentium4°l xiloli № US 5!W i!7|*j°£ tiMe^n *| Intel Mobile Celeron M 600MHz Low Power embedded CPU with heat sink solution SMD low ESR/ESL Polymer Aluminum Electrolytic capacitor Intel 82852GM/82801 DB system chipset Support boot-up from USD type external devices. Support 24bits LVDS, Dual channel Support Multi-word DMA and Ultra DMA/33/66/100 Line-in/Line-out/Mic-In, 4COM, 4 USB 2.0 ports RoHS compliant. Specifications Processor Intel mobile Celeron M 600Mhz Chipset Intel 82852GM NB, ICH4 SB System Memory One DDR 184-Pin DIMM socket, support up to 1GB DDR RAM BIOS 4M firmware HUB Award license BIOS, support boot- up from USB type external CD-ROM, HDD and FDD devices. Ethernet I 1 x RJ-45 connector, Intel 82551 support 10/100 Base-connector T interface. Audio Build-in audio function, integrated AC97 codec Connector(internal speaker-out 2W AMP): Mic-in, Line-in, Speaker-out external Watchdog timer Programmable 255-level time-out intervals Expansion Interface One 32-bit PCI expansion slot | ||||||||||||||||||||||
| Support power saving and Doze/Standby/Suspend modes. 0~60°C | ||||||||||||||||||||||
| Power Management Operating temperature | ||||||||||||||||||||||
| 62+63 | ||||||||||||||||||||||
| www.benecom.co.kr | ||||||||||||||||||||||
