| HHQOlOOOnOOT Benecom s quality products solutions | ||||||||||||||||||||||||
| ?\ WJt A | ||||||||||||||||||||||||
| Embedded CP | 4r'.'bem-600a | |||||||||||||||||||||||
| Intel Pentium 4M / Celeron CPU X|S Ahg7-f°| tìtoli M § 7feS|o| 7E BEM A|E|S2| £|§4 SM №0\ Ss. 0| JËSHMë USB 2.0Port, CF card port §0| №f>\ *IÏÏE|d| *NI g^ESS 7E Pentiun4°l ^|o|| fllif BOW i|7|sios éUHtf Intel Mobile Pentium M upto 2.1 GHz SMD low ESR/ESL Polymer Aluminum Electrolytic capacitor Intel 82852GM/82801 DB system chipset Support boot-up from USD type external devices. Support 24bits LVDS, Dual channel Support Multi-word DMA and Ultra DMA/33/66/100 Line-in/Line-out/Mic-In, 4COM, 4 USB 2.0 ports RoHS compliant. Specifications Processor Intel mobile P4 M CPU up to 2.1Ghz Chipset Intel 82852GM NB, ICH4 SB System Memory One DDR 184-Pin DIMM socket, support up to 1GB DDR RAM BIOS 4M firmware HUB Award license BIOS, support boot- up from USB type external CD-ROM, HDD and FDD devices. Ethernet I 1 x RJ-45 connector, Intel 82551 support 10/100 Base-connector I T interface. Audio Build-in audio function, integrated AC97 codec Connector(internal speaker-out 2W AMP): Mic-in, Line-in, Speaker-out external Watchdog timer Programmable 255-level time-out intervals Expansion Interface One 32-bit PCI expansion slot | ||||||||||||||||||||||||
| RoHS VGA connector LCD Interface IDE Serial Port USB Parallel Port USB K/B & Mouse IrDA Digital I/O | RoHS compliant 1 x DB-15 VGA connector supporting up to 1600 x 1200 1 x internet VGA pin head. 1 x LCD 30 pin header interface ( Support 24bits LVDS, Dual channel) Two enhanced IDE Support up to 4 devices including UDMA133/100/66/33 Mode Connector: One 40-pin & one 44 pin pin-headers. Four COM ports with ESD protected COM 1/2: RS232 DB-9 connector COM 3: RS232/422/485 DB-9 connector COM 4: RS-232 2x5 2.54 pitch pin-header Four 4 USB 2.0 port Connector: Two USB connector external / Two 2x4, 2.54 pitch pin-header internal One multi-mode parallel port (SPP/EPP/ECP) Four 4 USB 2.0 port Connector: Two USB connector external / One 2x4, 2.54 pitch pin-header internal Two 6-pin mini-DIM PS/2 K/B & mouse Connector One IrDA pin-header 4 digital-input / 4 digital-output | |||||||||||||||||||||||
| Support power saving and Doze/Standby/Suspend modes. 0~60°C 1 x 20 pins ATX power connector. Operating: 0°C~55°C Storage: -10°C ~70°C | ||||||||||||||||||||||||
| Power Management Operating temperature Power connector Temperature | ||||||||||||||||||||||||
| 60+61 | ||||||||||||||||||||||||
| www.benecom.co.kr | ||||||||||||||||||||||||
