| "С" | |||||||||||||||||||||
| Benecom's quality products solution siooon | |||||||||||||||||||||
| аРЕ№с<р1аГ Embedded CPU Board BEM-5CC | |||||||||||||||||||||
| Support power saving and Doze/Standby/Suspend modes. APM 1.2 / ACPI 1.0 compliant Connector: One ATX 20-pin & One 4-pin 12V connectors; One HDD 4T connector. 0~60°C 5%~95% Non-condensing 219mm x 159mm (8.6inch x 6.3inch) 350g Integrated Unichrome Pro graphic function, support dual-view (CRT/LCD simultaneously in different contents); 64MB UMA share memory One DB-15 connector (external) / One 2x8, 2.54 pin header (internal); resolution support up to 1600x1200 Support dual channel LVDS 18/36/24/48bit TFT panel Connector: One HIRSOSE 30-pin for LVDS Penmount DMC9000 touch controller onboard (socket type) Two enhanced IDE Support up to 4 devices including UDMA133/100/66/33 Mode Connector: One 40-pin & one 44 pin pin-headers. Four COM ports with ESD protected COM 1/2: RS232 DB-9 connector COM 3: RS232/422/485 DB-9 connector COM 4: RS-232 2x5 2.54 pitch pin-header Four 4 USB 2.0 port Connector: Two USB connector external / One 2x4, 2.54 pitch pin-header internal One SPP/EPP/ECP bi-directional port Connector: One DB-25 connector Two standard PS/2 for K/B & mouse Connector: One 6-pin 2.54 pitch pin header Support with K/B lock function (by hardware jumper setting and BIOS setting) "High/Low: enable/disable PS2 keyboard. One IrDA pin-header 4 digital-input / 4 digital-output | |||||||||||||||||||||
| Power Management Operating temperature Humidity Dimensions Net Weight VGA/LCD Controller VGA Interface LCD Interface Touch Controller (option) IDE Serial Port USB Parallel Port K/B & Mouse Note IrDA Digital I/O | |||||||||||||||||||||
| Intel Mobile Pentium M CPU X|S H^^ A|gJl°| £il|0|| 7fet\G\ 7\£ BEMA|E|*£l £|§4 £E 0| MH^Aib RoHS 7|£0| AH£0| *rc!E|Dj ^8 Cooling Fan2^ Pentium^ =#l|oil Pitt 3!om a^^og ^ijllsl&n xl*j a, *M^°-| Alg£| o| o_rg£§ ^lHH^ *H£°Jl|[:L Socket 478 supports up to P4M 2.5Ghz or P4C 2.4Ghz with PN800 main chipset. Unique P4 only 40mm height Heatsink Module for thermal solution Keyboard Lock Function External I/O connector to reduce cables usage. Dual-view to VGA & LCD simultaneously in different contents. LVDS interface supports 18/36/24/48bit flat panel. On-board 3M touch controller socket . Using solid-state capacitors (low ESR) on-board. Supports both SATA/PATA HDD. Supports CF socket. | |||||||||||||||||||||
| Specifications Processor I Intel P4 Socket 478 supports P4M/P4C CPU up to 3.01 Ghz with heatsink solution Chipset VIA PN800 / VT8237 System Memory One DDR 186-Pin DIMM socket, support up to 2GB DDR RAM I/O Chipset VIA VT1211 BIOS AWARD 512KB Flash ROM, support boot-up from USB Ethernet Realtek 8139C, 10/100 Base-T, wake on LAN Connector: One RJ-45 connector Audio Build-in audio function, integrated AC97 codec I Connector: Mic-in, Line-in, Speaker-out external Hardware Monitor Onboard Super I/O, monitor system / CPU temperature and voltage status Watchdog timer Programmable 255-level time-out intervals SSD interface Support type I & II compact flash socket | |||||||||||||||||||||
| 58+59 | |||||||||||||||||||||
| Expansion Interface One 32-bit PCI expansion slot | |||||||||||||||||||||
| www.benecom.co.kr | |||||||||||||||||||||
