O Embedded CPU Board

.¡'-'OldOOllOOr

Benecom s quality products solution siooon

bem-400

219mm x 159mm (8.6 inch x 6.3inch) 350g

Integrated S3 Savage4 graphic function, support dual-view (CRT/LCD simultaneously in different contents)

One DB-15 connector(external) / One 2x8, 2.54 pin header(internal); resolution support up to 1600 x 1200 Support TTL 18/24/36bit DSTN/TFT flat panel with 256 gray shade & LVDS 18/36bit TFT panel; resolution support up to 1024x768; Option LVDS 24bit TFT panel via daughter board.

One LCD 2x25, 2.0 pitch pin-header for TTL and one molex 5045-05A inverter connector; One HIRSOSE 30-pin for LVDS; Option 2x25, 2.0 pitch pin-header for LVDS daughter board.

Penmount DMC9000 touch controller onboard (socket type)

Two enhanced IDE Support up to 4 devices including UDMA100/66/33 Mode Connector: One 40-pin & one 44 pin pin-headers

Support NB type FDD Connector: One 26-pin 1.0 pitch connector

Four COM ports with ESD protected COM 1/2: RS232 DB-9 connector COM 3

RS232/422/485 DB-9 connector COM 4: RS-232 2x5 2.0 pitch pin-header

Four 4 USB 1.1 port Connector: Two USB connector external / One 2x4, 2.54 pitch pin-header internal

One SPP/EPP/ECP bi-directional port Connector: One DB-25 connector

Two standard PS/2 for K/B & mouse. One 6-pin 2.54 pitch pin header.

One IrDA pin-header

4 digital-input / 4 digital-output

Dimensions Net Weight

VGA/LCD

Controller VGA Interface LCD Interface

LCD Interface Connector Touch Controller (option)

IDE

FDD

Serial Port

USB

Parallel Port K/B & Mouse IrDA

Digital I/O

BEM-400^ VIA C3^ 733MHz CPU£ BEM-300B ME°\ ^ Hi 0K\. 0\MEO\\X]t VGA m|HE|f shered 32M°£ 3^ Sr*°o| 4?№l USB 2.0 Portl §4|5|0| *i USB X|S5|0| 2133 HDDLp

CD-ROM^ Ahgl §0|S|7|| SISc*. Fan-less CPU§ 7|§ *i 733MHzl 7feSM| siap.

VIA Eden 7000 733Mhz Low voltage CPU on-board

External I/O connectors to reduce cables usage

Dual-view to VGA & LCD simultaneously in different contents

On-board 3M touch controller socket

Using solid-state capacitors (low ESR) on-board

Specifications


	Processor	VIA Eden ESP7000 733MHz CPU onboard
	Chipset	VT8606 / VT82C686B
	System Memory	One DIMM socket, max. 512 MB SDRAM
	I/O Chipset	Winbond 83977
	BIOS	AWARD 256KB Flash ROM, support boot-up from USB
	Ethernet	Realtek 8139C, 10/100 Base-T, wake on LAN, Boot ROM and PXE functions. Connector: One RJ-45 connector
	Audio	Build-in audio function, integrated AC97 codec Connector: Mic-in, Line-in, Speaker-out external
	Hardware Monitor	Onboard Genesys GL518SM, monitor system / CPU temperature and voltage
	Watchdog timer	Programmable 8-level time-out intervals
	SSD interface	Support M-system DiskOnChip
	Expansion Interface	One 32-bit PISA expansion slot
	Power Management	Support power saving and Doze/Standby/Suspend modes. APM 1.2 compliant. Connector: AT/ATX co-design; One HDD 4T connector.
	Operating temperature	0~60°C
	Humidity	5%~95% Non-condensing

56+57
