| BElSEGp H O Embedded CPU Board | ||||||||||||||||||||||||
| bem-300b ut | ||||||||||||||||||||||||
| Floppy Drive One 2 x 17 x 2.54 mm FDD port (support up to two floppy devices) or one 1 x 26 x 1.0 mm FDD port (support Interface one floppy device) Serial Port Four COM ports with ESD protect, COM1 RS-232 DB-9 connector, COM2 RS-232 DB-9 connector, COM3 RS-232/422/485 DB-9 connector, (RS-485 Auto sensing), and COM4 for touch controller Parallel Port One multi-mode parallel port ( SPP/EPP/ECP ) DB-25 connector Universal Serial Bus Support two USB port connector IR Interface Supports one IrDA header Digital I/O Digital-in*4 and digital-out*4(2x5x2.54mm Header) Watchdog Timer Software 16 level time-out intervals (0/2/4/6/8/10/12/14/16/18/20/22/24/26/28/30 sec.) Touch Connector 8 pin molex connector Keyboard/Mouse Tow 6-pin mini-DIM PS/2 Keyboard and mouse connector Connector BIOS 256KB Award licence BIOS, Support boot-up from USB type external CD-ROM, HDD and FDD devices RTC I Internal RTC with Li battery Power management I/O peripheral devices support power saving and doze/standby/suspend modes. APM 1.2 compliant. Power Connector On-board power connector, with one ATX/AT co-design power connector optional and one HDD 4T connector Operating 0°C ~ 60°C Temperature Dimensions 219 x 159 mm +/- 0.5mm EMI/EMS Meet CE and FCC class B regulation, test service not include in design and layout charge Humidity 5% ~ 95 % RH, non-condensing Other function Support USB device boot up (FDD, HDD, CD-ROM) Supportb Dual VGA Alarm power on | ||||||||||||||||||||||||
| VIA VIA Eden 600MHz Fan-less CPU^ MSH±m|E|Ar^ a= ±, NS^ Geode, £1!, AMD°| CPU0]| ±h|S3§ yg x||£ °k 1.05V ±b|*iao| 14 3W0II 0|iP. Ofe 7|£°| CPU§ 7|§ y= ±b|*iao£ 0| MH1 AhgSrS CPU1 0| ME0||A-fe 2^^ USB Port, Integrated Audio, Integrated Network, Parallel Port, Digital I/O (Digital-in x 4 and digital-out X 4 (2X5X2.54mm)§0| X|«JSM 7|£2| JPC SERIESOllE 3§0| Specifications Processor Support VIA Eden 667 MHz EBGA Processor | ||||||||||||||||||||||||
| Chipset | ||||||||||||||||||||||||
| VIA82C686B, VT860A, Realtek RTL8139C, ALI M5113 super I/O, VT1611A audio chip, salt IC9000A/D | ||||||||||||||||||||||||
| System Memory One DIMM socket, One SO-DIM, support up to 512MB / RAM of SDRAM VGA connector One DB-15 VGA connector LCD connector One LCD 2 x 25 x 2.0 mm box-header and one molex I 5045-05A inverter connector (GND, 5V, 12V, ENABKL, I BLK_CONT) Sound connector Built-in sound functions, include Mic-in, Line-in, Speaker-out, BLK_VR external connectors, one CD-in, 1 x 4 x 2.54 mm pin-header (R, GND, GND, L) and one Speaker-out Molex 5045-4A connector with 3W output Ethernet I One RJ-45 connector, support 10/100 Base-T Connector I interface,wake on LAN, Boot ROM and PXE functions SSD interface Reserved socket for DiskOnChip from M-System, support up to 144 MB flash memory disk Expansion Bus Built-in one PISA expansion slot IDE Interface One 2 x 22 x 2.0 mm PCI IDE port, support up to two IDE devices. Supports PIO mode 4 and Bus Master. Also supports Multi-word DMA and Ultra DMA/33/66/100 | ||||||||||||||||||||||||
| 54+55 | ||||||||||||||||||||||||
| www.benecom.co.kr | ||||||||||||||||||||||||
