| i'-N.ilUOÜllOOl Benecom's quality products solutions | |||||||||||||||||||||||||||||||||
| BE№com m О Panel PC | |||||||||||||||||||||||||||||||||
| BNC-173 | |||||||||||||||||||||||||||||||||
| CD-ROMS'^!", USB User°l £\Ц H<fPentium | |||||||||||||||||||||||||||||||||
| Color • Black Silver Ivory | |||||||||||||||||||||||||||||||||
| Order Information BNC-173PN Intel Socket 478 Supports up to P4M/P4C/P4 3.06GHz. I 220W AC Power supply, 2.5" HDD with Anti-vibration kit, Slim X24 CD-ROM, 17.0" TFT, BEM-500A CPU board, High intensity Acryl panel BNC-173PT Intel Socket 478 Supports up to P4M/P4C/P4 3.06GHz. 220W AC Power supply, 2.5" HDD with Anti-vibration kit, Slim X24 CD-ROM, 17.0" TFT, BEM-500A CPU board, 17" 7 layers 3M analog resistive touch or 5 Wires resistive Touch Screen I/O Port | |||||||||||||||||||||||||||||||||
| '^IS- | |||||||||||||||||||||||||||||||||
| Intel Socket 478 Supports up to P4M/P4C/P4 3.06GHz. • Serial port: RS-232 x 2 + RS-232/422/485 x 1 (Internal Rs-232 x 1 for touch solution) • USB: 2 external + 2 internal Parallel Port: One SPP/EPP/ECP DB-25 connector • K/B & Mouse: Two standard PS2 for each K/B & Mouse. Audio: 1 x Line-out 1 x Line-in 1 x Mic in • IrDA: 1 x internal IrDA Digital IO: 4 digital in / 4 digital out 3 PCI (ISA Bridge riser card 2.5м HDD with Anti-vibration gage, x24 Slim Type removable CD-ROM 10/100 base Ethernet with wake on LAN, boot ROM, PXE • LCD brightness control function • Genesis GL518SM for self-diagnosis 1.5KV ESD protection function for serial ports which interface mostly with External devices. 7 Layers analog resistive 3M touch screen or 5 Wires analog resistive touch screen (optional) High intensity Acryl panel installing for protection of LCD (Without touch screen ) 220W Input voltage : 100~240V~/4~2A/60~50Hz Output voltage: +3.3V@17A, +5V@13A, +12V@16A, -12V@0.3A, 5Vsb@2A Operating temperature: 0°050°C (32-122T) • Relative Humidity: 5%~85%@40°c (non-condensing) Vibration (operation) 5~500MHz 1G RMS Random Vibration | |||||||||||||||||||||||||||||||||
| © © © ® © | |||||||||||||||||||||||||||||||||
| ф COM1/COM2 © Ethernet © Keyboard/Mouse ® Parallel © COM3 © USB ® CD-ROM(Removable) © Speaker-out/Mic-in/Line-in © LCD Brightness Control ® VGA | |||||||||||||||||||||||||||||||||
| Expansion slot(option) HDD & CD-ROM | |||||||||||||||||||||||||||||||||
| Ethernet Others | |||||||||||||||||||||||||||||||||
| © © © © ® | |||||||||||||||||||||||||||||||||
| Dimension | |||||||||||||||||||||||||||||||||
| 22+23 | |||||||||||||||||||||||||||||||||
| www.benecom.co.kr | |||||||||||||||||||||||||||||||||
