Easy to use handheld thickness gauge Suitable for most metallic and non-metallic materials Display current thickness or minimum thickness (menu selectable)Upper-lower limits setting and sound alarm Memory for 500 stored values Two point calibration Display resolution 0.1mm/0.01mm selectable Display in mm or inch
Industrial lcd display with adjustable backlight Low battery indicator RS232 output for data transfer
Technical specifications Transducer specification
Standard delivery
Measuring range (Steel) 1.2mm-225.0mm with 5MHz transducer Main unit Transducer 5P10 Rubber jacket Ultrasonic couplant Batteries AA 1.5V Screwdriver Instruction manual TIME certificate Warranty card Carrying case 1
11
121
1
111 5.0mm-300.0mm with 2MHz transducer Operating temperature -10 ć ~ +60 ć Lower limit steel pipes 20mm x 3.0mm Display resolution (Selectable) 0. 1mm/0.01mm or 0.01/0.001inch Data output RS232 Output for printer or pc Measuring accuracy ±1% thickness +0.1mm Sound velocity 1000m/s~9999m/s Power supply 2pcs AA batteries (2pcs) 1.5V Battery life 100 hours without backlight Dimensions 152mm×74mm×35mm
Weight 370g
Optional accessories
Transducer TSTU32 (2MHz) Transducer 5P10 Printer TA220S with cable Dataview with communication cable Transducer Measurement range Contact area diameter Frequency (MHz) Operating temp. TSTU32 5.0~300.0mm (Steel) 22mm 2 MHz -10 ć ~ +60 ć 5P¦Õ10 1.2mm-225.0mm (steel) 10mm 5 MHz -10 ć ~ +60 ć
