BETEX SUPER and GIANT upto 100 kVA
From 600 kg to 12,000 kg!
These are powerful heaters for heavy components.
Components can be heated horizontally or vertically.
For bore sizes of min. 85 mm to max. 3500 mm OD.
Many variations are possible.
Options are:
• Standard or TURBO version.
• Electric swivel arm for handling induction yokes
ergonomically.
• Horizontal yoke on a sliding support.
• Widened opening up to 1000 mm.
• Variable capacities up to 100 kVA.
• Temperatures max. 350 °C.
• Mobile.
• Flashing warning system.
• Infrared remote control.
Areas of application
• Machine construction
• Wind turbine manufacture
• Steel industry
• Railways
• Paper industry
• Mining
• Gearbox manufacturers
• Demagnetisation of fabricated
parts and bearings
BETEX® S U P E R a n d G I A N T
BETEX GIANT, 40- 48 kVA
Min. Ř 115 mm.
Max. outside diameter 1400-2500 mm.
Suitable for weight: 1500-3500 kg.
BETEX GIANT TURBO, 48- 100 kVA
Min. Ř 215 mm.
Max. outside diameter 1400 - 3500 mm.
Suitable for weight: 1500-12000 kg.
BETEX SUPER, 24 kVA
Min. Ř 85 mm.
Max. outside diameter 900-1300 mm.
Suitable for weight: 600 kg.
