CUSTOM-MADE and ACCESSORIES HEAT I N G T I M E S CUSTOM-MADE: INDUCTION FOR PRODUCTION Bega designs and builds custom-made heaters for serial heating of components such as bearings, gear wheels, bushes, rings and aluminium houses of E-motors. When fast and accurate heating is imperative, these ‘Specials’ offer surprising solutions. It is possible to integrate them in fully automated production processes, even with a pick-and-place unit. An additional advantage is the use of low frequency (50/60Hz), which costs much less than medium- or high-frequency solutions. A brochure with examples of ‘Specials’ is available on request. BETEX IMPACT 33 OR 39 FITTING TOOLSET For correctly mounting bearings, seal rings, oil seals, bushes, etc. For bore sizes of min. 10 mm to max. 130 mm OD. Magnetic temperature probe (a clamp probe is also available for non-ferrous components). Handy trolley. Using extension yokes. Extension yokes combined with 2 yokes on top of each other. Bega Special Tools, Schorsweg 15, NL-8171 ME Vaassen, The Netherlands T + 31 578 668000 F + 31 578 668080 sales@bega.nl www.bega.nl © Bega International BV. We reserve the right to alter technical specifications without prior notice.    ACCESSORIES AVAILABLE SEPARATELY: • Yokes • Extension yokes • Heat resistant gloves • Magnetic probe, various types • Sliding supports for horizontal heating COMPARISON HEATING TIMES BETWEEN STANDARD AND TURBO HEATERS Heating in horizontal position, to 110°C, in minutes. Bearing no. 23130 22240 23148 23156 175296 gearwheel Weight kg 16 kg 43,5 kg 63 kg 95,8 kg 220 kg 300 kg ID/OD mm 150/250 200/360 240/400 280/460 350/580 210/600 22 ELD 3,6 kVA 31.20 min. -- -- -- -- -- 24 RLD TURBO 3,6 kVA 07.26 min. -- -- -- -- 22 ESD 3,6 kVA -- 30.15 min. -- -- -- -- 24 RSD TURBO 3,6 kVA -- 10.05 min. 19.20 min. 45.00 min. -- -- 38 ESD 8 kVA -- -- 11.50 min. 23.00 min. -- -- 40 RSD TURBO 8 kVA -- -- 04.30 min. 08.57 min. 26.50 min. 15.00 min. 38 ZFD 12 kVA -- -- 09.55 min. 14.20 min. 39.50 min. 48.45 min. 40 RMD TURBO 12 kVA -- -- 02.15 min. 03.30 min. 08.40 min. 06.35 min.
