E Catalog Tube to tubesheet welding head

E Catalog Tube to tubesheet welding head
1 / 4 PagesView full catalog

E Catalog Tube to tubesheet welding head

Product catalog summary
Overview: This document provides technical specifications and features of AXXAIR's innovative orbital solutions for tube to tubesheet welding, specifically for diameters ranging from 10 mm to 80 mm.
Specifications:
  • Rotating joint for gas, current, and cooling.
  • Water-cooled tilt head with adjustable wire.
  • Carriage for head and wire adjustment.
  • Integrated rotating wire feeder with a diameter of 0.8 mm.
  • Wire feed speed adjustable from 0 to 1.5 m/min.
  • Power factor: 200 A at 100% duty cycle.
  • Weight: 7.5 kg (17 lbs) without wire spool, 8.5 kg (19 lbs) with wire spool.
Features:
  • Additional gas chamber and pneumatic clamping for enhanced performance.
  • Compatibility with AXXAIR power sources as per the compatibility table.
Accessories and Options:
  • Centering mandrils available in various sizes for precise alignment, ranging from 9.8 mm to 78.0 mm.
  • Centering cartridge groups (SATP-B01 to SATP-B04) for different diameter ranges.
Contact Information:
  • Address: 330B Route de Portes Les Valence - ZI Les Bosses - 26800 Etoile sur Rhône.
  • Phone: +33 475 575 070
  • Fax: +33 475 575 080
  • Email: [email protected]
  • Website: www.axxair.com
See more

Catalog excerpts

E Catalog Tube to tubesheet welding head-1

INNOVATIVE ORBITAL SOLUTIONS

 Open the catalog to page 1
E Catalog Tube to tubesheet welding head-2

TUBE SHEET RANGE INNOVATIVE ORBITAL SOLUTIONS ø10 - ø80 mm ø0,4'' - ø3'' - Rotating joint for gas, current and cooling - Water-cooled tilt head - Carriage for head and wire adjustment - Integrated rotating wire feeder (Ø 0.8 mm) - Wire feed speed from 0 to 1.5 m/min - Power factor: 200 A, 100% Weight: - 7.5 kg / 17 lbs without wire spool - 8.5 kg / 19 lbs with wire spool Water-cooled tilt head with adjustable wire Wire supply rotates along with head Driven by AXXAIR power source ( cf compatibility table ) Join Experience Pneumatic clamping 330B Route ZI Les Bosses - 26800 Etoile sur Rhône pied...

 Open the catalog to page 2
E Catalog Tube to tubesheet welding head-3

Accessories INNOVATIVE ORBITAL SOLUTIONS SATP-B01 : Centering cartridge group 1 SATP-M11 Centering mandril Centering mandril SATP-B03 : Centering cartridge group 3 SATP-M29 Centering mandril Join Experience 330B Route ZI Les Bosses - 26800 Etoile sur Rhône pied de page +33 475de Portes-Les Valence - 575 080 Tél: 575 070 Fax: +33 475 commerce@axxaircom - www.axxair.com

 Open the catalog to page 3
E Catalog Tube to tubesheet welding head-4

Dimensions INNOVATIVE ORBITAL SOLUTIONS Join Experience 330B Route ZI Les Bosses - 26800 Etoile sur Rhône pied de page +33 475de Portes-Les Valence - 575 080 Tél: 575 070 Fax: +33 475 commerce@axxaircom - www.axxair.com

 Open the catalog to page 4
