INNOVATIVE ORBITAL SOLUTIONS ORBITAL BEVELLING

BEVELLING MACHINES INNOVATIVE ORBITAL SOLUTIONS ø15 - ø121 mm ø0,5 to ø4,5 '' - Basic jaws Ø1” to 4,5” ( Ø24 to Ø121 mm ) - Included stainless steel auxiliary jaws Ø 0,25” to 4,25” ( Ø 15 to Ø 108 mm ) - Supplied with plastic protection and profile guide - Technology: screw carbide inserts: 10 x faster than HSS tools. Superior service life - Max 8 mm according to spinner* - Patented System - Scalability: may be transformed into a cutting and orbital welding machine - Weight: 37 kg / 82 lbs (easy handling) V bevel with profile guide roller J bevel with profile guide roller Outer profile guide...

BEVELLING MACHINES INNOVATIVE ORBITAL SOLUTIONS ø33 - ø170 mm ø1,25 to ø6,625 '' - Basic jaws Ø 2,75” to 6,625“ ( Ø70 to Ø170 mm ) - Included stainless steel auxiliary jaws Ø 0,625” to 4,65” ( Ø 33 to Ø 118 mm ) - Supplied with plastic protection and profile guide - Technology: screw carbide inserts: 10 x faster than HSS tools. Superior service life - Max 8 mm according to spinner* - Patented System - Scalability: may be transformed into a cutting and orbital welding machine - Weight: 44 kg / 97 lbs (easy handling) V bevel with profile guide roller J bevel with profile guide roller Outer profile...

BEVELLING MACHINES INNOVATIVE ORBITAL SOLUTIONS ø59 - ø225 mm ø2 to ø8,625 '' - Basic jaws Ø4,55” to 8,625” (Ø116 t oØ 225 mm ) - Included stainless steel auxiliary jaws Ø 2” to 6,65” ( Ø59 to Ø 169 mm ) - Supplied with plastic protection and profile guide - Technology: screw carbide inserts: 10 x faster than HSS tools. Superior service life - Max 8 mm according to spinner* - Patented System - Scalability: may be transformed into a cutting and orbital welding machine - Weight: 51 kg / 112 lbs (easy handling) V bevel with profile guide roller J bevel with profile guide roller Outer profile guide...

BEVELLING MACHINES INNOVATIVE ORBITAL SOLUTIONS ø140 - ø330 mm ø5,5 to ø12,75'' - Basic jaws Ø 8,5” to 12,75”( Ø 216 to Ø 330 mm ) - Included stainless steel auxiliary jaws Ø 5,5” to 10 “ ( Ø 140 to Ø 256 mm ) - Supplied with plastic protection and profile guide - Technology: screw carbide inserts: 10 x faster than HSS tools. Superior service life - Max 8 mm according to spinner* - Patented System - Scalability: may be transformed into a cutting and orbital welding machine - Weight: 73 kg / 161 lbs (easy handling) V bevel with profile guide roller J bevel with profile guide roller Outer profile...

Accessories INNOVATIVE ORBITAL SOLUTIONS Cutting motors Cutting motor 230V mono : FS29 : Thickness Inox < 5 mm FS25 : Thickness Inox > 5 mm SAEP-00 : electric rotation autoline CC121 to CC321 ( 120 V - 230V ) Cutting motor 120V mono : FS19 : Thickness Inox < 5 mm FS15 : Thickness Inox > 5 mm MOPD: pneumatic motor All motors are delivered in their individual case, including the necessary tools Join Experience bevelling motors 330B Route de Portes Les Valence - ZI Les Bosses - 26800 Etoile sur Rhône Tél: +33 475 575 070 - Fax: +33 475 575 080 commerce@axxaircom - www.axxair.com V3.8-06-2016

Accessories INNOVATIVE ORBITAL SOLUTIONS CCBSB-001: bench with height adjustment - 1.5 m - CC121ECO -> CC321 CCBSB-002: additional 1.5 m bench - CC121ECO -> CC321 CCPS21: support feet - CC121ECO -> CC321 CCSER1/CCSER2: simple/bearing stand Join Experience 330B Route de Portes Les Valence - ZI Les Bosses - 26800 Etoile sur Rhône Tél: +33 475 575 070 - Fax: +33 475 575 080 commerce@axxaircom - www.axxair.com V3.8-06-2016

Consumables INNOVATIVE ORBITAL SOLUTIONS TV-300: 30° spinner with guide roller (Max 8mm) TV-375: 37.5° spinner with guide roller (Max 7mm) TV-450: 45° spinner with guide roller (Max 6,5mm) KS30: insert tightening tool TJ-100: 10° J spinner with guide roller (Max 8mm) Join Experience 330B Route de Portes Les Valence - ZI Les Bosses - 26800 Etoile sur Rhône Tél: +33 475 575 070 - Fax: +33 475 575 080 commerce@axxaircom - www.axxair.com V3.8-06-2

INNOVATIVE ORBITAL SOLUTIONS Join Experience 330B Route de Portes Les Valence - Zl Les Bosses - 26800 Etoile sur Rhone commerce@axxaircom - www.axxair.com
