AW Company Full Line Catalog (Ver. 06/05)
49Pages

Flow meters, monitors and controllers >

Flow ranges 0.003 to 120.0 GPM ׷ Six Flow Ranges available Accuracy ױ 0.5% of reading Aluminum, 303 and 316 SS bodies ׷ Pressure rating up to 5,000 PSI Pulse, mAand Voltage Sensors available ׷ Bi-Directional flow capabilities Economical cost > The JV-KG Series represents a positive displacement meter that is affordable and accurate. One primary feature is the ability to maintain consistent accuracy despite changing viscosity conditions. This reliability, coupled with a large turndown range, offers an affordable replacement for older turbine technology. The meterגs solid construction and...

Model Sensor Types Sensor Features HEF-xx Single Sensor - standard Frequency output DH-xx Dual Sensor with x2 resolution Single or quadrature frequency output MAG-xx Hall Effect Single Sensor Frequency output, with conduit connection FIP-xxx Meter Mounted Analog Output Sensor 3 wire analog output, current or voltage CAPM-xx Single Sensor XX = Consult factory or see price list for complete part number Frequency output CAPM-15 High Temp Sensor to 400԰F for Stainless Steel Separated pickup & amplifier module QUAD-4 Quad Sensor with x4 Resolution Single or quadrature frequency, -80KL& -90KL...

ַ 316 SS bodies Xylan coated bolts ׷ Flow ranges 0.003 to 7 GPM Accuracy ױ 0.5% 15,000 PSI working pressure ׷ Bi-Directional flow capabilities ATEX approved, non-sparking ׷ Medium pressure Autoclave connections > The JVHS series of positive displacement flow meters are designed for high pressuresystems requiring flow meters rated up to 15,000 psi (1035 bar) working pressure. The JVHS meters are equipped with medium pressure autoclave connections, 316 SS bodies and xylan coated bolts. The flow meters are bi-directional and can be hydrotested to 1.5X the working pressure rating. Acomplete...

Materials of Construction: Body: 316 Stainless Steel > Gear: Stainless Steel O-Ring: Teflon Bearings: Stainless Steel Flow Range (GPM) Options Accuracy: ֱ 0.5% over 10:1 turndown with 30 cPfluid 12 = 0.003 - 0.8 KG = Standard Unit Repeatability: 0.1% 20 = 0.01 - 2.0 KG-Ex = Explosion Proof Max Fluid Temperature: 30 = 0.03 - 7.0 Meter 400Ѱ F Stainless Body Example:JVHS-12KG-Ex Has a flow range of 0.003 to 0.8 GPM, and is modified to accept an explosion proof sensor. NOTE: Meter can be hydrotested to 1.5x working pressure. PortingMedium PressureAuto Clave PressureRating(PSI) Meter Type...

Flow ranges 0.001 to 20 GPM ׷ 6 Flow ranges available Accuracy ױ 0.5% of reading Stainless Steel construction ׷ Pressure rating up to 5000 PSI Pulse, mAand Voltage Sensors available ׷ Economical cost Bi-directional flow capabilities > The JVM Series flow meters are economical and reliable positive displacement flow meterssuitable for a wide variety of paints and industrial fluids. The principal of operation is that of a gear pump, but in reverse; instead of the gears driving the medium, the medium drives the gears. Anon-intrusive sensor detects the movement of the gears and produces a...

Accuracy: 0.5% over 10:1 turndown with 30 cPfluid Materials of Construction: Body: JVM - 303 SS Gear: Stainless Steel Repeatability: ѱ 0.1% O-Ring: Teflon / Viton optional Temperature: 180 C / 350а F Bearings: Tungsten Carbide Ports: NPT, BSPPavailable Specify upon ordering Shafts: Tungsten Carbide PressureRating(PSI) Meter Type RangeGal/Min Impulse/Gallon Impulse/cc Dia(in) Ports Filtration(micron) Wt(lbs) JVM-01CG 0.001 to 0.25 155,000 41 3.0 1/4 120 3.0 5,000 JVM-10CG 0.003 to 0.5 100,300 26.5 3.0 1/4Ԕ 120 2.9 5,000 JVM-15CG 0.01 to 1.0 31,000 8.2 3.3 1/4 120 4.5 5,000 JVM-20CG 0.02 to...

Flow ranges 0.003 to 2.0 GPM ׷ Compact for tight spaces Accuracy ױ 0.5% of reading 303 and 316 SS bodies ׷ Pressure rating up to 2000 PSI Manifold Mount or Threaded Port ׷ Special Titanium coated gears Fiber Optic or Pulse Sensorsavailable upon request > Automotive paint systems place extreme demands on their components. For over 15 years, AW brand flow meters have met these demands, and more. The JVS-SLG and HPM-SLG Positive Displacement Flow Meters feature smaller, lighter bodies than traditional flow meters, making them easier to install on robotic arms and in tight spaces. These meters...

Titanium coated gears available for water based fluids Model Sensor Types Sensor Features CAPM-3o Single Sensor - ULApproved Intrinsically safe, frequency output when used with a barrier Fiber Optic System FOP30/S includes: FOP-30 Fiber Optic Sensor Fully isolated optical signal OPTV-20 Light to Frequency Converter Converts optical output to frequency output Fiber Optic Cable Standard Heavy Duty Fiber Optic Cable Available in 30, 40, 60 & 100 foot lengths Products may be subject to change without notice Ԗ Contact factory for current information Fiber Optic System FOP30/SJVS-XX SLGFS or...

Flow ranges 0.001 to 265 GPM ׷ Great for multi-viscosity fluids Accuracy ױ 0.5% of reading 303 SS or 316Ti bodies ׷ Pressure rating up to 9000 PSI Long operating life > The ZHM series positive displacement flow meters are ideally suited for multi-viscosityfluid measurement. Manufactured of stainless steel and tungsten carbide, the ZHM meter can be used with abrasive fluids as well as those fluids under high pressure. The ZHM measures a small volume of liquid as each gear tooth passes the sensor. The uncompromised manufacturing tolerances prevents slippage of fluid even at the lowest flow...

5-Pin Amphenal Plug 1 = +U 2 = Signal push pull 3 = O V 4 = Open collector signal (collector) 5 = Open collector signal (emitter)5-Pin Amphenal Plug 1 = +U 8-30 VDC2 = Signal out- push pull/open collector 3 = O V 4 = Signal out- push pull/open collector 5 = Common emitter for pins 2 & 4Open collector outputs All sensors: Pulse High = Supply -1.2V High temperature sensors are available up to 180C / 350а F >

Flow ranges 0.003 to 105 GPM ׷ 5 Flow ranges available Turn down ratio of over 1:100 ׷ 303/316 stainless steel construction Pressure rating up to 6000 PSI ׷ Lower pressure loss Great for highly filled &abrasive fluids ׷ High resolution > The SRZ series represents a helical gear flow meter that is constructed of two highly accuratecycloid shaped screw spindles that mesh and rotate inside the cylindrical housing with two overlapping holes in the form of a figure 8, which forms the measuring chamber. The medium flows in an axial direction rotating the spindles without pulsation.The SRZ helical...
