Rev. 02/06 EMO-3000 PIDSeriesMulti Channel Flow computer EMO 3000/3/PID PID T echnical Dat EMO 3000/4/PID a EMO 3000/1/PID EMO 3000/2/PID 1 Channel Closed LoopController in an enclosure with
trigger pressure switch, lights,
manual set point knob, manual
flush switch, 1 I/PConverter,
Heavy Duty Power Supply,
Intrinsically Industrial safe Barrier Card
and a 2 AMPFused Power
Inlet 2 Channel Closed Loop
Controller in an enclosure with
trigger pressure switches,
lights, manual set point knob,
manual flush switches, 2 I/P
Converters, Heavy Duty Power
Supply, 2 Intrinsically Safe
Barrier Cards and 2 AMP
Fused Power Inlet
Products may be subject to change without notice – Contact factory for current information TRIG INPUT 1 TRIG INPUT 2 1
SET REACHED ON FLUSH ON FLUSH OFF OFF TRIGGER TRIGGER I/P OUTPUT 1 SET REACHED
2 I/P OUTPUT 2 SET POINT SET POINT 0% 100% 0% 100% 3 Channel Closed LoopController in an enclosure with
trigger pressure switches,
lights, manual set point knob,
manual flush switches, 3 I/P
Converters, Heavy Duty Power
Supply, 3 Intrinsically Safe
Barrier Cards and a 2 AMP
Fused Power Inlet 4 Channel Closed LoopController in an enclosure with
trigger pressure switches,
lights, manual set point knob,
manual flush switches, 4 I/P
Converters, Heavy Duty Power
Supply, 4 Intrinsically Safe
Barrier Cards and 2 AMP
Fused Power Inlet 115 VAC IN METER 1
100 PSI AIR IN METER 2 Optional Sof tware Package: The GR-3000 Flow control Software will allow the user to
upload and download PID parameters directly to the EMO-3000, format color tables and graph flow rates and
trigger times. T ypical EMO 3000 PID Application PNEUMATIC TRIGGER SIGNAL The diagram at right shows a typical
2 channel closed loop control scheme
with the EMO-3000/2/PID. Each flow
loop includes a paint supply line, flow meter manufacturer, fluid regulator and industrial spray gun.The EMO-3000/2/PID receives asignal from each flow meter and, with
its self-contained I/Pconverter, con-
trols the fluid regulator to precisely
and accurately deliver paint, air or
other fluid. TRIGGER SIGNAL REGULATORSUPPLYPAINT ROBOT FLOWMETERFLUID 1
SET REACHED ON FLUSH ON FLUSH OFF OFF PNEUMATIC TRIGGER SIGNAL TRIGGER TRIGGER SET REACHED
2 SET POINT SET POINT 0% 100% 0% 100% FLUIDFLOWMETER TRIGGER SIGNAL FREQUENCY FEEDBACK FROM FLOWMETER ROBOTPAINT SUPPLYREGULATOR 110 VAC FREQUENCY FEEDBACK FROM FLOWMETER
PNEUMATIC CONTROL SIGNAL 8809 Industrial Drive, Franksville, WI 53126 Phone: (262) 884-9800 Fax: (262) 884-9810Email: awinfo@aw-lake.com www.awflowmeters.com
|
