The Weigh Bar

® The Weigh Bar is the patented weight sensor designed by It has proven to be the most dependable and long-livedweight sensor in the industry. The Weigh Bar is virtuallyunaffected by wear, everyday jolts, weather and other normal environmental hazards. Weigh-Tronix to stand up to the rigors of hard, everyday use.The Weigh Bar automatically cancels side loading, end loading,and torsion, measuring only the vertically applied load.

Specifications

Standard sizes and capacities:

Accuracy:
CapacityModelDimensionsDimensions–cm Meets or exceeds NTEP class III 5000 division accuracy.
2,000 lbLP3636-02*3' x 3' x 2"91 x 91 x 5(1,000 kg)5,000 lbLP4848-05*4' x 4' x 2"122 x 122 x 5(2,500 kg)LP7248-05*6' x 4' x 2"182 x 122 x 5LP6060-055' x 5' x 2"152 x 152 x 5LP7248-10*6' x 4' x 2"182 x 122 x 5LP6060-10*5' x 5' x 2"152 x 152 x 510,000 lbLP7260-10*6' x 5' x 2"182 x 152 x 5(5,000 kg)LP8460-10*7' x 5' x 2"213 x 152 x 5LP9660-108' x 5' x 2"244 x 152 x 5LP7272-106' x 6' x 2"182 x 182 x 5LP6060-20*5' x 5' x 2"152 x 152 x 5LP7260-20*6' x 5' x 2"182 x 152 x 5LP8460-20*7' x 5' x 2"213 x 152 x 520,000 lbLP9660-208' x 5' x 2"244 x 152 x 5(10,000 kg)LP7272-206' x 6' x 2"182 x 182 x 5LP9672-208' x 6' x 3"244 x 182 x 8LP10884-209'' x 7' x 3"274 x 213 x 8LP108144-209' x 12' x 3"274 x 366 x 830,000 lbLP9672-308' x 6' x 3"244 x 182 x 8(15,000 kg)40,000 lbLP10884-409' x 7' x 3"274 x 213 x 8(20,000 kg) Temperature: 14° to 104°F (-10° to 40°C) Agencies: NTEP CC#88-222Canadian Weights and MeasuresFactory Mutual Dimensions: PlatformABCD4' x 4' x 2"49"47"57
1 /
2 "109"5' x 5' x 2"61"59"71"121"6' x 4' x 2"73"47"57
1 /
2 "133"7' x 5' x 2"85"59"71"145"6' x 6' x 2"73"71"83"133"8' x 5' x 2"97"59"71"157"9' x 7' x 3"109"83"99"199"9' x 12' x 3"108"144"159"209" *Standard sizes available in stainless steel Finish: (carbon steel models)2-3 mil layer of epoxy primer, 2 mil layer of alkyd enamel or 2-3 mil of high grade powder paint finish (on sizes upto 6060-05). Construction: Unique sandwich constructed platform area with treadplate in either carbon or stainless steel material. All cabling routed within the assembly to eliminate potentialdamage from exposed wires. Weight sensors: Four Weigh-Tronix Weigh Bars
® Overload protection: 150%
Avery Weigh-Tronix 1000 Armstrong Dr. Fairmont, MN 56031 USA Telephone: 507-238-4461Facsimile: 507-238-4195e-mail: industrial@weigh-tronix.com www.wtxweb.com End loading: 100%
Avery Weigh-Tronix Canada, ULC 217 Brunswick Boulevard Pointe Claire, QC H9R 4R7 Canada Telephone: 514-695-0380Toll free: 800-561-9461Facsimile: 514-695-6820 www.weigh-tronix.ca Weigh Bar ® is a registered trademark of Weigh-Tronix Inc2/03 LOWPRO_L.P65 PN 08905-0017C Printed in USA
