Cargo Scales

Lift Iruck Scale for

ITA Class III/IV Carriages

Robust Scale Design —

The durability of Weigh-Tronix's lift truck scale is immediately apparent. The scale's patented design features a heavy-duty carriage comprised of two solid metal plates coupled together by application designed Weigh Bar® weight sensors. The inherent strength of the carriage plates allows the assembly to incorporate two huge viewing ports which provide the operator a clear line of sight to the forks.

The Weigh Bars electronically measure the load on the forks and convey this information to a summing and angle detection box. The box is constructed of stainless steel and placed between two metal plates for added protection.

The Weigh Bar cables are enclosed within metal guards for environmental protection. Even travel stops have been designed-in to prevent forks from sliding off either end. The entire carriage assembly is primed and finished with a durable epoxy paint.

Certified Accuracy —

The system's IDC (Independent Discrimination Compensation) feature ensures the system will maintain legal-for-trade accuracy under typical application variables: changing fork positions, unlevel wheels, or tilted mast. This is documented on the U.S. Department of Commerce, National Institute of Standards and Technology, certificate number 95-126A2.

Instrumentation —

Lift Truck Scales use a choice of two indicators, the basic WI-125 or the SimulCast™ with advanced data management.

The WI-125 is a simple no nonsense instrument. Its LCD display provides excellent visibility in direct sunlight and has an automated backlight for low-light environments. The impact resistant enclosure features rounded corners for safety.

Capacities available from 5,000 lbs to 16, 000 lbs.

Models for ITA cleat type carriage heights of 16", 20" and 24".

SimulCast has an electroluminescent multi-line display. It simultaneously displays current weight and related data. Its database can store up to 750 records. Peripheral input devices such as scanners and bar code wands are compatible. Downloading the data can be accomplished by infrared or RF to printers, PCs, or mainframes.

SimulCast

WI-125
