| 3700LP Bench Bases | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Features & Benefits: | Specifications: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Connects to external indicators - Connects to a variety of Avery Wfeigh-Tronix indicators, such as the WI-125 (shown below). Convenient selection of sizes - Choose from 3 sizes with capacities from 10 to 250 lbs to fit the needs of any application. Stainless steel shroud - Resists corrosion and makes cleaning easy. Reliable - Low maintenance. Single load cell design with no moving parts. Durabridge construction - (on 250 lb base) Less than 1/2" of deflection in the base. Minimizes shock load and offcenter loading error. Options: Ball top kit - Ideal for in-line conveyor applications. Minimizes lifting and speeds processing. Extended cable length - For applications that require more than the standard 10' of interface cable. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Cable length - All bases come with 10 feet of four conductor interface cable. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Excitation - Up to 15 VDC (generated by weight display). Output - 2mV/V. Overload - Up to 200% of scale rated capacity. Operating environment - 41 °F to 104°F (5°C to 40°C). 10 to 95% relative humidity, non-condensing. Agencies - NTEP Pending (5,000 divisions Class III, CO.C # 02-069), UL/CUL | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 3735LP model shown with optional Avery Weigh-Tronix WI-125 indicator. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Avery Weigh-Tronix | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| AUTHORIZED DISTRIBUTORS Ask the experts. Weigh-Tronix distributors are complete support centers, providing needs assessment, technical information, product sales and service. Their experience is a valuable resource that is readily available to you. We recommend you consult these knowledgeable industrial applications specialists for all of your weight measurement needs. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Fairmont, Minnesota U.SA. USA Toll-Free: 800-368-2039 USA Phone: 507-238-4461 www.wwtxweb.com Pointe Claire, Quebec Canada CAN Toll-Free: 800-561-9461 CAN Phone: 514-695-0380 www.weigh-tronix.ca 7/04 3700LP_L.p65 - C&D PN 09870-0016 e2 Printed in USA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
