Your ALS 306

at a glance




Dispensing speed:	up to 60 m/min
Labels:	Material:self-adhesive label with liner
	Winding direction:	inside/outside winding possible
	Label roll diameter:	400 mm
	Backing paper roll diameter:	270 mm
	Core diameter:	38.1 mm / 76.2 mm / 101.6 mm (1.5" / 3" / 4")
	Material width:	10 to 160 mm, including backingpaper
	Label length:	10 to 600 mm
	Label stop accuracy	at variable speed: < ±1 mm at continuous speed: < ±0,5 mm
Electronics:	Processor	32 Bit CPU MIPS-Core, 16 MB ROM, 4 MB ROM
	Card-Slot	slot for 1 compact-flash-card
	Remote Display	graphical display with 128 x 32 Dots, 2/4 lines, 5 buttons, multi-langual
	Interfaces:	RS 232, Ethernet, USB Device, I/O Interface, Applicator Interface, PLC Interface
	Remote Display connection:	RS485 (Mini DIN 6)
Sensor interfaces for	(using 4-Pin M12 plugs)
external sensors:
	Label sensor:	optical, NPN, 24 V, controllable sensitivity
	Alternative label sensor:	PNP/NPN, 24 V
	Product sensor:	PNP/NPN, 24 V
	APSF-Sensor (rotary encoder):	single-phase/two-phase, PNP/P-P, 24 V
	OD label roll sensor:	PNP, 24 V
Dimensions:	w x h x d (without unwinder):	726 x 389 x 386 mm
Environment:	Weight:	55 kg
	System voltage:	100-240 V
	Power consumption:	max. 510 VA
	Operating temperature	5 to 40°C
	Humidity	30 to 85% (not condensing)
	Qualification	CE, TUV/GS, FCC, CCC, GOST, NRTL, US/CA
Options	additional material guide disc, several Applicators, remote display, L-Shape dispensing edges: fixed, swivelling, pneumatic or spring-loaded, Tandem function, Applicator Interface board, 2nd 400 mm unwinder module, internal or external OD labelroll sensor
