FOR SOLIDS
The huge success of these devices is essentially due to the reliability and the simplicity of its installation. To stop the filling of storing areas or silos, three models of SOLIBA are available forapplications in both non-hazardous and hazardous areas. The offered prices are notably low.All SOLIBA detectors work by tilting in connection with filling system circuit. This method is obviouslyvery simple, reliable and inexpensive.For hazardous atmospheres (potentially explosive dust or gas), the 2 models SOLIBA P (“Dust”)or GP (“Gas and Dust”) are certified according to the EC type certificate LCIE 00 ATEX 6003 X inconformance with the Directive 94/9/CE and standards EN 50014, 50281-1-1, 50281-1-2,50020, zones 0, 1, 2 and 20, 21, 22, Group IIC, temperature class T6.A separate instruction sheet provides all details for wiring these devices. The GP version must obligatory be associated to an intrinsic safety relay.
SOLIBA SOLIBA (SF2000 ECO)
ATEX
The regulation devicescertified ATEX are nowcompulsory in the majorityof the silos. They allow in
total security the stoppingof the silos’ filling and the“Alarm” detection at the
high level in complement
with other detectionmethods. They are very easyto set up and inexpensive. ATEX
CAUTIONThe non-respect of the“Low Voltage” Directives
and the “Intrinsic Safety”instructions or a use whichis not specified by theconstructor and the intervention of non competent authorities cantrigger serious consequences.The manufacturer deniesall responsibility if theuser does not respect the
instructions and rules in
relation with the protectionsagainst sanitary, fire andexplosion risks. Differential angleDifferential angleDifferential angle For further information, please, refer to the individual technical sheets.
Non certified “P” version “GP” version
Operation mode Use By tilting
Stopping of the silos filling By tilting
Stopping of the silos filling By tilting
Stopping of the silos filling (cereals, pulverulents)
Only in “non explosive“ areas (cereals, pulverulents)
Especially for work in explosive areas (cereals, pulverulents)
Especially for work in explosive areas Important specification 20, 21, 22 T6 i.e. from - 20 C to + 70 C / 0, 1, 2 and 20, 21, 22
T6 i.e. from - 20 C to + 70 C Maximum temperature 85°C idem for storage idem for storage Protection index Power supply IP 68 IP 6X
240 VAC - 50/60 Hz IP 6X
24 VAC/VDC - 10 mA
or 12 VAC/VDC 100 mA
With intrinsic safety relay 250 VAC - 50/60 Hz Cut-out power 20 (8) A (20 A resistive - 8 A inductive) 1 A (protection by means of a 1 A fuse) Wiring Reverser
microswitch
Biconical / cylindrical shell Silver / Cd oxide contacts
Copolymer polypropylene Silver / nickel contacts
Copolymer polypropylene Gold plated contacts
Copolymer polypropylene + HR HY (hypalon) vulcanized + HR HY (hypalon) vulcanized Cable 3 cond. 1mm
2 Neoprene H07RN8-F HR HY (hypalon) H07RN8-F HR HY (hypalon) H07RN8-F Float size Height 152 mm 95 mm Height 260 mm 92 mm Height 200 mm 92 mm Float weight without cable 462 g 495 g 495 g Cable weight Neoprene 115 g/m HR HY 110 g/m HR HY 110 g/m Adjustable ballast on cable (option)
Standard cable lengths (series) Loaded resin 250 g 5, 6, 10, 13, 15, 20 and 30 m Loaded resin 250 g 5, 10, 15, 20, 25 and 30 m Loaded resin 250 g 5, 10, 15, 20, 25 and 30 m (other lengths on request)
DETAILS ABOUT THE SOLIBA (SF 2000 ECO) CERTIFIED ATEX
Concerning the silos for cereals, everybody knows the continuous existence of the explosive risks triggered by dust and gas.Our SOLIBA certified ATEX are fitted with a double envelop and are especially designed to be used in the most important explosive risks areas. It complies with the following utilization norms:
- The “P” version can be used in areas classified 20, 21, 22 (dust).- The “GP” version can be used in areas classified 0, 1, 2 (gas) and 20, 21, 22 (dust) - Float highly recommended.These two devices which are simple to install and inexpensive enable to stop the silos filling in a total security but also to get an “alarm” level detection what is very often neglected and therefore very useful. So, think about the SOLIBA .For any further information, please refer to our website www.atmi.fr from which you can download various documentation.
