Zubehôr Abtrieb - Synchron-Zahnriementriebe - Zahnriemen-Teilung 8 M (8 mm)

HTD®-Zahnriemenràder fur Klemmbuchsen (Patent Dodge Taper-Lock und System Vecobloc®) Output accessories - Synchronous toothed belt drives - Toothed belt-pitch 8 M (8 mm)

HTD®-toothed pulleys for clamping bushes (Patent Dodge Taper-Lock and System Vecobloc®)


Typ 8F		Typ 8A	Typ 8WF Typ 8W			Typ 3F	Typ 4F	Typ 5F
HDT® 8 M-30 (Zahnriemenbreite / Tothed belt width 30 mm)
Bestell-Nr. Int. Zahnez. Typ Mate-Order code Code-Nr. no.of Type rial b d_bCode no. teeth				4 d_w	D	H D, t s È		Klemmbuchsen C lamping bushes Bestell-Nr. Bohrung Order code Bore
31 62 544	44-8M-30 44	4F GG	38 119,0	110,67 112,05	-	-	91 3 32 1,33	80 11 025 25
31 62 548	48-8M-30 48	4F GG	38 127,0	120,86 122,23	-	-	95 3 32 1,78	80 11 025 25
31 62 556	56-8M-30 56	4F GG	38 148,0	141,23 142,60	-	-	117 3 32 3,76	80 11 025 25
31 62 564	64-8M-30 64	8F GG	38 168,0	161,60 162,97	125	45	- - - 4,20	80 13025 25
31 62 572	72-8M-30 72	8WF GG	38 192,0	181,97 183,35	125	45	158 - - 4,30	80 13025 25
31 62 580	80-8M-30 80 8W GG		38 -	202,35 203,72	125	45	180 - - 4,60	80 13025 25
31 62 590	90-8M-30 90 8A GG		38 -	227,81 229,18	125	45	204 - - 5,00	80 13025 25

HDT® 8 M-50 (Zahnriemenbreite / Tothed belt width 50 mm)

Bestell-Nr. Int. Zahnez. Typ Mate- x Klemmbuchsen

Order code Code-Nr. no.of Type rial b d_b d_k d_w D H D, t s m Clamping bushes

rode no teeth Bestell-Nr. Bohrung

code no. teetn _0rder _code _Bofe


31 64 530	30-8M-50 30	5F GG	60 83,0	75,13	76,39	-	-	58 22,0	- 0,65	80 08 025 25
31 64 532	32-8M-50 32	5F GG	60 87,0	80,16	81,49	-	-	62 22,0	- 0,82	80 08 025 25
31 64 534	34-8M-50 34	5F GG	60 91,0	85,22	86,58	-	-	65 22,0	- 1,06	80 08 025 25
31 64 536	36-8M-50 36	5F GG	60 98,5	90,30	91,67	-	-	68 22,0	- 1,30	80 08 025 25
31 64 538	38-8M-50 38	5F GG	60 103,0	95,39	96,77	-	-	72 22,0	- 1,60	80 08 025 25
31 64 540	40-8M-50 40	4F GG	60 106,0	100,49	101,86			82 14,0	32 1,20	80 11 025 25
31 64 544	44-8M-50 44	4F GG	60 119,0	110,67	112,05	-	-	91 14,0	32 1,71	80 11 025 25
31 64 548	48-8M-50 48	4F GG	60 127,0	120,86	122,23			95 14,0	32 2,30	80 11 025 25
31 64 556	56-8M-50 56	4F GG	60 148,0	141,23	142,60	-	-	116 7,5	45 3,40	80 13 025 25

Andere Teilungen, Zàhnezahlen und Rlemenbrelten slnd auf Anfrage ebenfalls lleferbar. / Other pltches, number of teeth and belt width available on request.

Klemmbuchsen - Patent Dodge Taper-Lock und System Vecobloc® Clamping bushes - Patent Dodge Taper-Lock and System Vecobloc®


Bestell-Nr. Int. Mate- X Order code Code-Nr. rial d, H B T EU Code no.
80 03 025	12 10 GG 25	25 8	28,3	0,20
80 07 025	16 10 GG 25	25 8	28,3	0,34
80 08 025	16 15 GG 25	40 8	28,3	0,50
80 11 025	20 12 GG 25	30 8	28,3	0,67
80 13 025	25 17 GG 25	45 8	28,3	1,57
80 15 025	30 20 GG 25	50 8	28,8	2,92

Lieferung in Kartons einschlieBlich Schrauben und Montageanleitung Delivery in cardboard boxes incl. screws and mounting instruction

MaBe / Dimensions in mm

C-11
