rftTLflNTfh

Bestell- Abtriebs- Abtriebs- Betriebs- Motor- Getriebe Gewicht Maßbild

Nummer Drehzahl Drehmoment faktor bezeichnung Nr. Seite


Order Output Output Service Motor Gear Weight Dimensions code speed torque factor designation no. page n₂ (min-¹) M₂ (Nm) f_B (kg)
4,0 kW
4,0 kW
55 27 051 28 1024	0,90 112M4 56 27 051 69,0	B-9
55 27 582 35 712 55 27 139 37 809	1,20 S112M2 56 27 082 64,0 1,30 112M4 56 27 039 69,0	B-9 B-9
55 27 561 47 555	1,80 S112M2 56 27 061 64,0	B-9
55 27 751 56 506	1,60 112M2 56 27 051 64,0	B-9
55 26 120 74 456	1,05 112M4 56 26 020 59,0	B-9
55 27 120 74 451	2,00 112M4 56 27 020 69,0	B-9
55 26 115 99 335	1,45 112M4 56 26 015 59,0	B-9
55 25 520 149 215	0,95 S112M2 56 25 020 46,0	B-8
55 26 720 149 226	1,75 112M2 56 26 020 54,0	B-9
55 25 515 200 164	1,30 S112M2 56 25 015 46,0	B-8
55 26 715 200 166	2,45 112M2 56 26 015 54,0	B-9
55 25 107 213 165	1,25 112M4 56 25 007 51,0	B-8
55 26 107 213 165	2,35 112M4 56 26 007 59,0	B-9
55 24 507 430 80	1,05 S112M2 56 24 007 40,5	B-8
55 25 707 430 81	2,15 112M2 56 25 007 46	B-8

5,5 kW

55 27 039 37 1109 0,95 112MX4 56 27 039 82 B-9

55 27 651 55 706 1,15 112MX2 56 27 051 84 B-9

55 27 020 74 618 1,45 112MX4 56 27 020 82 B-9

55 26 015 99 460 1,05 112MX4 56 26 015 72 B-9

55 27 620 147 311 2,50 112MX2 56 27 915 84 B-9

55 25 007 213 226 0,90 112MX4 56 25 007 64 B-8

55 26 007 213 226 1,70 112MX4 56 26 007 72 B-9

55 25 607 424 114 1,55 112MX2 56 25 007 66 B-8

7,5 kW

55 27 551 55 956 0,85 112MV2 56 27 051 89 B-9

55 27 539 74 756 1,20 112MV2 56 27 039 89 B-9

55 27 115 99 634 1,50 132M4 56 27 015 105 B-9

55 26 520 148 426 0,95 112MV2 56 26 020 79 B-9

55 27 520 148 421 1,85 112MV2 56 27 020 89 B-9

55 26 515 199 313 1,30 112MV2 56 26 015 79 B-9

55 27 107 213 312 2,45 132M4 56 27 007 105 B-9

55 26 507 427 154 2,15 112MV2 56 26 007 79 B-9

11,0 kW_

55 27 015 99 930 1,00 S160M4 55 27 015 122 B-9

55 27 515 200 462 1,75 S160M2 55 27 015 117 B-9

55 27 007 213 457 1,65 S160M4 55 27 007 122 B-9

55 27 507 430 227 2,85 S160M2 55 27 007 117 B-9
