Bestell- Abtriebs- Abtriebs- Betriebs- Motor- Getriebe Gewicht Maßbild

Nummer Drehzahl Drehmoment faktor bezeichnung Nr. Seite


	Order Output Output Service Motor Gear Weight Dimensions code speed torque factor designation no. page n₂ (min-¹) M₂ (Nm) f_B (kg)
	1,5 kW (Fortsetzung / Continuation)
	1,5 kW (Fortsetzung / Continuation)
	55 25 639 71 154	1,55 90S2 56 25 039 30,0	B-7
	55 25 120 72 167 55 24 015 97 124	1,40 90L4 56 25 020 32,0 0,95 90L4 56 24 015 26,5	B-8 B-8
	55 25 215 97 127	1,95 90L4 56 25 015 32,0	B-8
	55 24 620 146 80	1,25 90S2 56 24 020 24,5	B-8
	55 25 820 146 82	2,45 90S2 56 25 020 30,0	B-8
	55 24 615 197 61	1,70 90S2 56 24 015 24,5	B-8
	55 23 515 204 57	0,85 S90S2 56 23 015 22,0	B-7
	55 24 107 207 62 55 23 607 422 30	1,60 90L4 56 24 007 26,5 1,45 S90S2 56 23 007 22,0	B-8 B-7



	55 27 082 17 800	1,05 S100L4 56 27 082 56,0	B-9
	55 26 061 23 605 55 27 161 23 623	0,85 S100L4 56 26 061 46,0 1,85 S100L4 56 27 061 56,0	B-9 B-9
	55 26 051 27 553	0,90 S100L4 56 26 051 46,0	B-9
	55 27 251 27 569	1,65 100L4 56 27 051 56,0	B-9
	55 26 582 35 374	1,20 90L2 56 26 082 38,0	B-9
	55 26 039 36 438	1,05 S100L4 56 26 039 46,0	B-9
	55 27 339 36 450	2,35 100L4 56 27 039 56,0	B-9
	55 25 561 46 283	0,95 S90L2 56 25 061 33,0	B-8
	55 26 661 46 301	1,50 90L2 56 26 061 41,0	B-9
	55 26 651 55 276	1,55 90L2 56 26 051 41,0	B-9
	55 25 539 71 227	1,20 90L2 56 25 039 33,0	B-8
	55 25 020 72 242	1,00 S100L4 56 25 020 38,0	B-8
	55 25 115 97 184	1,35 S100L4 56 25 015 38,0	B-8
	55 24 520 146 117	0,85 90L2 56 24 020 27,5	B-8
	55 25 720 146 120	1,70 90L2 56 25 020 33,0	B-8
	55 24 515 197 89	1,15 90L2 56 24 015 27,5	B-8
	55 25 715 197 92	2,20 90L2 56 25 015 33,0	B-8
	55 24 007 209 90	1,10 S100L4 56 24 007 32,5	B-8
	55 25 307 209 91	2,25 100L4 56 25 007 38,0	B-8
	55 23 507 422 44 55 24 707 422 45	1,00 S90L2 56 23 007 25,0 1,90 90L2 56 24 007 27,5	B-7 B-8



	55 27 061 23 841	1,40 S100LX4 56 27 061 62,0	B-9
	55 27 151 28 768 55 27 682 35 541	1,20 100LX4 56 27 051 62,0 1,60 S100L2 56 27 082 57,0	B-9 B-9
	55 27 239 37 607	1,75 100LX4 56 27 039 62,0	B-9
	55 26 561 46 409	1,10 S100L2 56 26 061 47,0	B-9
	55 27 661 46 421	2,40 S100L2 56 27 061 57,0	B-9
	55 26 551 55 374	1,15 S100L2 56 26 051 47,0	B-9
	55 27 851 55 384	2,10 100L2 56 27 051 57,0	B-9
	55 26 220 74 382	1,35 100LX4 56 26 020 52,0	B-9
	55 26 639 74 296	1,35 S100L2 56 26 039 47,0	B-9
	55 25 015 99 248	1,00 S100LX4 56 25 015 44,0	B-8
	55 26 215 99 251	1,95 100LX4 56 26 015 52,0	B-9
	55 25 620 147 163	1,25 S100L2 56 25 020 39,0	B-8
	55 26 820 147 171	2,35 100L2 56 26 020 47,0	B-9
	55 25 615 198 124 55 25 207 213 123	1,70 S100L2 56 25 015 39,0 1,70 100LX4 56 25 007 44,0	B-8 B-8
	55 24 607 424 61	1,40 S100L2 56 24 007 33,5	B-8
