| rftTLRNTfti | ||||||||||||||||||||
| Anstrich | Paint finish | |||||||||||||||||||
| Normalanstrich Eignung für Klimagruppe "moderate" nach ICE 721-2-1 Innenraum- und Freiluftaufstellung, kurzzeitig bis 100 % relative Luftfeuchte bei Temperaturen bis + 30 °C, dauernd bis 85 % relative Luftfeuchte bis + 25 °C. | Normal finish adapted for group of climates Moderate acc. to IEC 721-2-1 Weatherprotected an non-weatherprotected locations open-air-conditions, short-time urn tp 100 % rei. humidity at temperatures up to + 30 °C, continously up to 80 % rei. humidity uo tp + 25 °C Finish system Sizes 56 - 112 - all components except aluminium terminal box: prima plastic paint, layer thickness about 30 urn - finis coat water-soluble varnish with layer thicknesses between 30 urn and 60 urn - special finish on request (2K-varnish), layer thickness > 30 urn Sizes 132 - 160 - prime coat plastic resin/zincphosphate, layer thickness about 30 urn - finish coat 2K-(separate-application)-polyurethane varnish, layer thickness > 30 urn Special finish adapted for group of climates World wide according to IEC 721-2-1 Non-weatherprotected locations, open-air conditions, in aggressive atmospheres (chemical industries, sea environments), short-time up to 100 % rei. humidity at temperatures up to + 35 °C, continuously up to 98 % rei. humidity uo tp + 30 °C Finish system Sizes 56 - 112 - all comp. prime plastic paint, layer thickness about 30 urn - finish coat water-soluble varnish with layer thickness between 60 urn and 90 urn Sizes 132 - 160 - prime coat plastic-resin/zincphosphate, layer thickness about 60 urn - second coat on separate-application base, layer thickness about 60 urn - finish coat, separate-application polyurethan varnish availabale on request Standard colour RAL 7031 blue-grey Further special coating systems - version for excessive thermal stresses - version for excessive chemical and radiation stresses - systems on customer's request | |||||||||||||||||||
| Farbaufbau BG 56 - 112 - alle Bauteile außer Kunststoffteile (Klemmenkasten, Lüfterhaube) und Aluminiumklemmenkasten Kunststoffgrundfarbe, Schichtdicke > 30 um - Deckanstrich Wasserlack mit Schichtdicken 30 um bis 60 um - Sonderwunsch 2-Komponenten-Lack, Schichtdicke > 30 um BG 132 - 160 - Kunstharz-Zinkphosphat-Grundierung, Schichtdicke > 30 um - Deckanstrich 2-Komponenten-Polyurethan, Schichtdicke > 30 um Sonderanstrich Eignung für Klimagruppe world wide nach IEC 721-2-1 Freiluftaufstellung in aggressiver Chemie- und Seeatmosphäre, kurzzeitig bis 100 % relative Luftfeuchte bei Temperaturen bis + 35 °C, dauernd bis 98 % relative Luftfeuchte bei Temperaturen bis + 30 °C | ||||||||||||||||||||
| Farbaufbau BG 56 - 112 - alle Bauteile Kunststoffgrundfarbe, Schichtdicke > 30 um - Deckanstrich 2-Komponenten-Lack, Schichtdicken > 60 um | ||||||||||||||||||||
| BG 132 - 160 - Kunstharz-Zinkphosphat-Grundierung, Schichtdicke > 60 um - Zwischenanstrich auf 2-Komponenten-Basis, Schichtdicke > 60 um - Decklack 2-Komponenten-Sonderlackierungen auf Anfrage | ||||||||||||||||||||
| Standardfarbton RAL 7031 blaugrau Weitere Sonderanstrichsysteme - Ausführung für hohe thermische Belastung - Ausführung für hohe chemische und Strahlenbelastung - Sonderanstrich Kundenwunsch | ||||||||||||||||||||
