General details Measurement specification

Temperature range Operating -10Ëš to 50ËšC Function Range Accuracy (1) Power supply 110/240V,50 to 400 Hz AC, 150VA Altitude: -2,300 to 60,000ft ±3ft at 0ft Case: Completely weatherproof,meets ±8ft at 30,000ft EMC requirements - MIL STD 462D ±32ft at 60,000ft Physical: 320mm x 270mm x 715mm (case) -700 to 18,000m ±1m at 0m 440mm x 420mm x 715mm (overall) ±2.5m at 9,000m 32 kg (71 lbs) ±10m at 18,000m Calibration: Recommended period 12 months Altitude rate: Up to ±6,000ft/min ±1% Ease of Use Remote touch screen max.±2,000m/min ±1% Wheeled case for manoeuvrability Indicated airspeed: 10 to 800kts ±2kt at 50kts Integrated bag for cables and hoses

PITOT STATIC TESTER - ADSE 745 - 7689 RVSM COMPLIANT

±0.14kt at 500kts Ease of maintenance: Modular design permitting ease ±0.07kt at 800kts of accessibility to mechanical 20 to 1480km/h ±3km/h at 100km/h assemblies and electronic ±0.26km/h at 900km/h components ±0.13km/h at 1480km/h Mach No: 0.1 to 4.0 Mach ±0.002M at 0,8M/25,000ft

Optional

±0.004M at 1,7M/30,000ft Multi-pressure outlet (3 Ps & 3 Pt) variant Static sensor 30 to 1200 mbar 0,01% FS (1) Power supply : 17 to 32V DC Pitot sensor 30 to 3000 mbar 0,01% FS (1) Rechargeable 24V nickel-cadmiun battery pack (1,5h) (1) linearity + repeatability + hysteresis at ambiant +10° to +40°C Higher vacuum unit for up to 15,000ft/min and 80,000ft x 1,5 for -10° to +50°C Specific Pt sensor for best airspeed accuracy for helicopter x 0,5 for ±2°C lab use Integrated screen for UAV use Remote Control Software for PC (Windows 2000 & XP)

ATEQ-OMICRON - 8, route de Chevreuse - F78117 - Chateaufort - France - Tél : +33 (0)1 39 075 002– Fax : +33 (0)1 39 075 019 - e-mail : aero@omicron.ateq.com
