Principle of measurement

FLOW MEASUREMENT

RANGEACCURACYMAXIMUMRESOLUTION 5 l/h30 l/h150 l/h 500 l/h1 500 l/h 4 000 l/h10 000 l/h + (2.5% D + 0.005 l/h)+ > 1 % of full scale> (2.5% D + 0.030 l/h)+ 1 % of full scale> (2.5% D + 0.150 l/h)+ 1 % of full scale> (2.5% D + 0.5 l/h)+ 1 % of full scale> (2.5% D + 1.5 l/h)+ 1 % of full scale> (2.5% D + 4 l/h)+ 1 % of full scale> (2.5% D + 10 l/h) 1 % of full scale
D = Flow 380

PRESSURE MEASUREMENT

RANGEACCURACYMAXIMUM RESOLUTIONFS = 75 mbar+ (1,5% of P + 0.2 hPa)0,1% of full scaleFS
* RelativeFS = Full Scale P = Pressure FS

MECHANICAL PRESSURE REGULATOR -20 - 80 kPa / 0.8 - 6 kPa / 0.5 - 14 kPa / 10 - 200 kPa / 40 - 400 kPa / 80 - 600 kPa

Technical specifications Measurement ranges

Physical Weight: approximately 7 kg

Accessories

Interface Start/Reset remote controlIntelligent remote control RC5PrinterParameter storage modulesATEQ software(WINATEQ - S5 DEMO)Needle valveMaster jetFiltration kitVacuum pumpSealing connectorsPlease refer to ATEQaccessories list Navigation keys 4-line LCD display Results indicator lights External electrical supply Voltage: 24 V DC / 2 A Main adaptater included (110 - 240 V AC) Air supply Clean and dry air required Air quality standard to be applied (ISO 8573-1) Temperature Operating:+ 10°C to + 45°C Storage:0°C to + 60°C

Head office:15, rue des Dames - ZI des Dames - 78340 Les Clayes-Sous-Bois - France : + 33 (0)1 30 80 10 20 - Fax: + 33 (0)1 30 54 11 00 - e-mail: info@ateq.com www.ateq.com
