Flexmag

™

Flexmag

™

ProductsInclude: ™

Products &Capabilities

Basic dimensional guidelines for Flexmag Strip and Sheet product: STRIP SHEET Thickness: 0.030" to 0.375" Thickness: 0.010" to 0.375" Width: 0.25" to 6.00" Width: 0.25" to 24.312" Energy: 0.50 to 1.90 MGOe Energy: 0.65 to 1.60 MGOe Standard Lengths:As much of the strip weproduce is custom,lengths are available on request.We have run up to 15,000' continuous lengths. Standard Lengths:25',50',100' lengths stocked,other lengths available by request.We have run up to 3,000' continuous lengths. Other capabilities or secondary conversion available from Flexmag:•Laminates•Pre-cut lengths,pieces or blanks •Kiss-cut strips•Retail-ready packaging •Die-cut shapes•Variety of standard adhesives •Custom magnetic pole patterns•Special length reels •Private label packaging•Back printed or embossing Flexmag is part of the International Arnold Group and our resourcesspan the globe.We have additional engineering resources throughoutthe U.S.,U.K.and Asia,and we can source products for you from around the world.

The Pole to Pole Leader in Flexible Magnetics

Our World TouchesYour World Every Day.

For more information contact us at: UNITED STATES

EUROPE ASIA

Marietta,OH,USA1-800-543-4426 Barlborough,UK44-1246-570-500 Hong Kong,China852-3106-3737

info@arnoldmagnetics.com

ResponsiveInnovativeQuality Driven

© 2004 Arnold

www.arnoldmagnetics.com or www.flexmag.com

6/04 Printed in the U.S.A.
