Text version of the page
| > 1U Rackmount Computer > up to 2.83GHz Core 2 QUAD Processor > up to 4GB DDR2 667/800 RAM > up to 2x Swappable SATA HDD's > Capable of RAID-0, RAID-1 > 6x USB 2.0, 3x RS-232/422/485 > lx PCI Expansion Slot > Dual! 0/100/1000M Ethernet | ||||||||||||||||||||||||||||||
| RS 102-AT front view | ||||||||||||||||||||||||||||||
| RS 102-AT Specifications | RS 102-AT Line Drawings | |||||||||||||||||||||||||||||
| CPU CPU (optional) RAM RAM (optional) HDD Bays HDD Drives available RAID levels available Disc Drive Disc Drive (optional) Expandability Connectivity Dimensions Mounting Front I/O | Intel 2.13GHz Core 2 Duo Intel 2.83GHz Core 2 Quad 1GB DDR2 667/800 up to 4GB DDR2 667/800 up to 2x Swappable/Lockable 40GB, 80GB, 120GB, 160GB SATA 0,1 Slim CD-RW Slim DVD-RW lx PCI Slot 2x 10/100/1000M GbE 17.0" wide, 1.73" tall, 19.06" deep 4x front screws lx Front locking access panel 2x USB 2.0 1 x Disc Drive 2x Lockable Swappable HDD Bays 3x RS 232/422/485 6x USB 2.0 2x RJ-45 lxVGA lxPS/2 Keyboard lx PS/2 Mouse | |||||||||||||||||||||||||||||
| Rear I/O | ||||||||||||||||||||||||||||||
| 17.50" | ||||||||||||||||||||||||||||||
| 1.25 | 1.71" | |||||||||||||||||||||||||||||
| 18.26" | ||||||||||||||||||||||||||||||
| Numerous rackmount conligjro'icn: and chassis types are ava'i'oDie Call Arisla for current contigurations.technical specifications and pricing. | ||||||||||||||||||||||||||||||
| RS 102-AT | ||||||||||||||||||||||||||||||
| Arista Corporation - 1.877.882.8742 | ||||||||||||||||||||||||||||||
