Reflow Oven Brochure - GF-120, 1800, & 2000 Series Reflow Ovens table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:5.00pt "Arial", sans-serif; } .font1 { font:9.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } .font3 { font:11.00pt "Arial", sans-serif; } .font4 { font:13.00pt "Arial", sans-serif; } .font5 { font:24.00pt "Arial", sans-serif; } .font6 { font:30.00pt "Arial", sans-serif; } Novastar ADVANCED ASSEMBLY SYSTEMS Wave olderim EWS-310 Wave Soldering Machine Prototyping Product Development Short Run, High-Mix Manufacturing Applications Quickly load and unload PCBs with finger conveyor Continuously adjustable PCB width from 1 to 12 inches User friendly touch screen LCD for programming and parameter adjustment Streamline design for Easy Maintenance and Cleaning System Features • Finger conveyor for pallet-less operation • Visibility throughout entire process with clear viewing Plexiglass® hoods • Onload and offload conveyor extensions • Durable, rugged welded steel frame construction • Fully dry wave, no oil intermix required • Stainess steel solder pump impellers with external ball bearings • Laminar wave for through hole component soldering • Motorized conveyor width adjustment • Fluxer and air knife pressure regulators • Solder level sensor alarm • Solder drain with stainless steel valve • On-board profiler • Lead-free solder capable Dual Wave Option shown above - tabulant wave for SMD (optional) and laminar wave for through-hole soldering. Recirculating finger cleaner option with spray spout and brushes Solder level sensor with alarm
