ROTRON Regenerative Blowers



Regenerative Blowers - 14270 Regenerative Principle Blower Features and Benefits

The impeller blades passing the inlet port draw airor other gasses into the blower. The impeller blades then, by centrifugal action, accelerate the air out- ward and forward. Here the “regenerative” principle takes effect as the air is turned back by the annular shaped housing to the base of the following blades where it is again hurled outward. Each “regenera- tion” imparts more pressure to the air. When the air reaches the stripper section at the outlet (the strip- per is the part of the blower located between the inlet and the outlet in which the annulus is reduced in size to fit closely to the sides and tips of the impeller blades) the air is “stripped” from the impeller and diverted out of the blower. The pres- sures or vacuums generated by the one or two spinning, non-contacting, oil-free impellers are equal to those obtained by many larger multi-stage or positive displacement blowers.

DR (Domestic Regenerative)

•Teflon lip seal in a stainless steel case standard for leakage containment to 25 cc/min or less•Explosion-proof motors standard and available in a variety of world voltages•All metal-to-metal surfaces are sealed with RTV sealant Our industrial DR regenerative blowers include:•Rugged cast aluminum housing, cover, impeller and muffler tower•Removable cast iron flanges bolted to a sheet metal manifold•TEFC motors on single-ended models, ODPmotors on all double-ended models•Carbon steel shaft and zinc plated hardware•Permanently sealed motor bearings for 20,000-25,000 hours life

CP (Chemical ProcessingRegenerative)

Our chemical processing/specialty gas CPblowersare designed the same as DR/EN blowers except added features include:•Chem-Tough
™

EN (Environmental Regenerative)

surface conversion corrosion resistant treatment for all castings•Teflon lip seal in a stainless steel case standard for leakage containment to 25 cc/min or less•Chemical duty motors with 303 stainless steel motor shafts•Stainless steel hardware throughout•Nickel plated flanges and muffler retainers Our environmental EN blowers are designed the same as the DR blowers, except added features include:•Heavy duty cast aluminum manifold•Our spark resistant housing, cover, impeller, muffler tower and manifold are vacuum impregnated
Rev. 2/04 i AMETEK Technical and Industrial Products, Kent, OH 44240 • e mail: rotronindustrial@ametek.com • internet: www.ametektmd.com
