Ready-to-use pressure systems for the DPC-500, APC, CPC, and IPI calibrators
AMETEK Calibration Instruments offer several solutions for pressure generation. This line spans from a small pneumatic “bicycle” type pump to a hydraulic pump
that generates up to 1,000 bar / 5,000 psi. These are durable pumps with
features such as vernier valves, vent valves, manifold connections, swivel fittings,
and optional O-ring materials and fittings making the pumps flexible to meet any
calibration and testing applications.
For all pressure systems the pump and the indicator are separate systems. Therefore a replacement of the pump does not mean that it is
necessary to send the complete system for repair. Maintenance of the
instrument is also made easy. Recalibration of the unit can be performed
locally with an accurate pressure reference: No need to send the unit
back to the manufacturer for recalibration. If a factory calibration is required, the pump and indicator are independent and only the indicator
needs to be returned.JOFRA pressure calibrators are as standard delivered as individual indica-tors or as a complete calibration systems ready to use in a carrying case,
including pump, hose, set of fittings, batteries, test leads, user manual,
and a traceable calibration certificate.
AMETEK Calibration Instruments is one of the world’s leading manufacturers and
developers of calibration instruments for temperature, pressure and process signals as well as for temperature sensors both from a commercial and a technological point of view. JOFRA Temperature Instruments Portable precision thermometers. Dry-block and liquid bath calibrators: 4 series, with more than 25 models and temperature ranges from -90° to 1205°C / -130° to 2200°F. All featuring speed, portability, accuracy and advanced documenting functions with JOFRACAL calibration software. JOFRA Pressure Instruments
Find more information in specification sheet SS-CP-2105 at www.jofra.com
Convenient electronic systems ranging from -1 to 1000 bar (25 inHg to 14,500 psi) - multiple choices of pressure ranges, pumps and accuracies, fully temperature-compensated for problem-free and accurate field use. JOFRA Signal Instruments Process signal measurement and simulation for easy control loop calibration and measurement tasks - from handheld field instruments to laboratory reference level bench top instruments. JOFRA / JF Marine Instruments A complete range of calibration equipment for temperature, pressure and signal, approved for marine use.
Pump system A Pump system B Pump system C
DPC-500, APC, CPC, and IPI0 to 2 bar / 30 psi 0 to 21 bar / 300 psi
-0.850 to 0 bar / 25 to 0 inHg DPC-500, APC, CPC, and IPI-0,95 to 35 bar / 14 psi to 500 psi DPC-500, APC and IPI0 to 200 bar / 3,000 psi 0 to 350 bar / 5,000 psi FP Temperature Sensors A complete range of temperature sensors for industrial and marine use. M&G
Pressure testers Pneumatic floating-ball or hydraulic piston dead weight testers with accuracies to 0.015% of reading. M&G Pumps Pressure generators from small pneumatic “bicycle” style pumps to
hydraulic pumps generating up to 1,000 bar (15,000 psi).
Pump system D Pump system E Pump system F
...because calibration is a matter of confidence
DPC-500, APC and IPI
0 to 350 bar / 5,000 psi DPC-500, APC and IPI0 to 700 bar / 10,000 psi DPC-500, APC and IPI0 to 1,000 bar / 14,500 psi
