JOFRA DPC-500 Documenting Pressure Calibrator
The JOFRA DPC-500 is designed for high precision calibration of pressure gauges, transmitters, digital manometers, pressure switches and overpressure valves. The documenting feature makes it possible to handle 16 work-orders,
with up 22 calibration points each and have the result uploaded to a PC via JOFRACAL calibration software.
• Accuracy to ±0.025% F.S.• Available as an indicator or in a complete system
• 43 pressure ranges up to 1000 bar (vacuum / gauge / compound / absolute) • Interchangeable DPC-J reference sensor (up to 5 sensors per instrument)• 15 standard pressure units (+ one user-definable)
• RS232 interface and JOFRACAL calibration software
JOFRA APC Advanced Pressure Calibrator
The JOFRA APC pressure calibrator is user-friendly, extremely accurate, and expandable to meet multiple applications. Features such as RS232 capability, loop sourcing, 17 engineering units, switch test, min/max readings,
and mA% calculations make this an invaluable calibration instrument.
• Accuracy to ±(0.04% of reading + 0.01% F. S.)• Available as an indicator or in a complete system
• Pressure range vacuum to 700 bar / 10,000 psi
• External APM pressure module capability• Reads and sources transmitters• Supplied with fittings for NPT and BSP threads
• RS232 interface and JOFRACAL calibration software Find more information in specification sheet SS-CP-2181 at www.jofra.com
Find more information in specification sheet SS-CP-2180 at www.jofra.com
Find more information in specification sheet SS-CP-2179 at www.jofra.com
Find more information in specification sheet SS-CP-2182 at www.jofra.com
JOFRA CPC Compact Pressure Calibrator
The JOFRA CPC pressure calibrators is designed for accuracy and ease of use. The CPC has the features needed in a pressure test and calibration tool: 17 engineering units, switch test, min/max readings, and mA reading.
• Accuracy to ±0.05% F. S.• Available as an indicator or in a complete system
• Pressure range vacuum to 15 bar / 200 psi
• Measures loop current to 24 mA• Min/max readings and switch test function• Supplied with fittings for NPT or BSP threads
• RS232 interface and JOFRACAL calibration software
The JOFRA IPI pressure indicator combines the ease of an analog gauge with the accuracy and easy-to-read display of a digital calibrator. The IPI offers a long battery life, high accuracy, and serial communication. The accuracy of the
IPI rivals a pressure calibrator and is temperature compensated for shop or machine room applications.
• Accuracy to ±0.05% of F.S. • Available as an indicator or in a complete system
• Pressure range vacuum to 700 bar / 10,000 psi
• 17 different and 1 user-definable pressure units• Min/max readings• Ex Certified by CSA as conforming to relevant Canadian and USA standards
JOFRA APM Advanced Pressure Module
The JOFRA APM pressure modules extend the usage of the JOFRA APC pressure calibrator as well as the ASC300 and AMC900 multi-function signal calibrators. The modules are available in a series of accuracies, ranges, units,
and pressure references from vacuum to absolute pressure. All APM modules contain the calibration data. Just
connect the modules to the instrument and perform the measurement.
Find more information in specification sheet SS-CP-2190 at www.jofra.com • Accuracy to ±0.01% F. S.• Pressure range vacuum to 700 bar / 10,000 psi
• 62 different modules
• Rugged and dependable for field or lab use• Gauge, absolute, vacuum, differential, and combination modules• Supplied with fittings for NPT and BSP threads 2 www.jofra.com
