Filtercart for additional filtration of hydraulic systems According to the recommendations of the manufacturers of the military equipment with integrated hydraulic systems, the hydraulic oil has to be changed every 1, 2, or 3 years. However, the need to change oil and filters no longer depends on what is recommended by the manufacturers, but is depicted by the hydraulic system itself. The contamination level (90% of the failures is caused by debris such as, sand/dirt particles, wear metals and water contaminants in the hydraulic system) needs to be maintained at an acceptable level to determine whether or not the oil and system filters need to be changed. Savings The most obvious cost of contaminated oil is machine downtime. The number of times you need to replace pumps, valves etc. is directly related to the condition of the oil in the system. The total cost of replacing oil increases as the cost of disposing contaminated oil grows. The use of a filtercart will decrease the times needed to change the oil and as a result, lead to lower disposal costs. TECHNICAL DATA Types:
for hydraulic fluid H-540 (NSN: 4320-17-107-1784)
for hydraulic fluid C-635 (NSN: 4320-17-105-7981 )
mineral oil according to DIN 51524/51525 Filterelements:
type “Spin-on” with two parallel filters
filtration ratio â3 = 200 (lSO 4572)
max. pressure 10 bar and max. flow 600 I/min. E-motor:
230 VAC ±10%, 50 Hz, 1 phase
other voltage and frequency optional Pump:
viscosity up to 800 cSt at -10°C
proportional flow 8 - 27 I/min.
max. suction pressure 0.7 bar
safeguarded against pumping without flow AMCA HYDRAULIC FLUID POWER B.V. P.O.BOX 18, 9790 AA Ten Boer Tel. +31 (0)50 3023577 B.Kuiperweg 33, 9792 PJ Ten Post Fax. +31 (0)50 3021226 The Netherlands email: sales@amca-nl.com homepage: http://www.amca-nl.com AMCA-FILTERCART Series CC-KL AMCA Hydraulic Fluid Power BV
