Publ.T-APV16-E-03-09 Model (1) table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:10.00pt "Arial", sans-serif; } .font2 { font:11.00pt "Arial", sans-serif; } .font3 { font:11.20pt "Arial", sans-serif; } Proportional Directional Control Valve Load-Sensing Pressure Compensated Electrical, Manual and Hydraulic opération Features. * Modular assembly System, suitable for 'build-systerrï. * Max. operating pressure 420 bar. * Différent spooltypes up to 330 l/min. in combination with simultaneously control. * Compact sandwich design, suitable for mobile applications. * Several inlet plate types available for différent types of pumps. * Operating control in any combination (electrical, manual and hydraulic). * Adjustable AP for setting the maximum flow. * Several user relief options as primairy-, shock-, suction- and remote control functions. * One full flat surface for mounting in any position. Publ.T-APV22-E-04/09
