Section 14

Engineering Data


Typical Catalog Number (1329RS)	HP	Synch RPM	Frame	FL RPM	Enclosure	Amps @ 460 Volts			Torque (ft. lb.)			Nom. Eff	Power Factor	NEMA Code	Sound Pressure @3ft. "A" scale	Rotor Inertia (Lb Ft.^A2
Typical Catalog Number (1329RS)	HP	Synch RPM	Frame	FL RPM	Enclosure	FL	LR	BD	FL	LR	BD	Nom. Eff	Power Factor	NEMA Code	Sound Pressure @3ft. "A" scale	Rotor Inertia (Lb Ft.^A2
VA04036FCH	40	3600	324TS	1765	TEFC	46 8	237	124	90 0	204	236	91 7	84 1	G	-	3 01
VA04018FCH	40	1800	324T	1765	TEFC	49 8	237	124	90 0	204	236	93	84 1	G	-	4 83
VA04012FCH	40	1200	364T	1765	TEFC	49 3	237	124	90 0	204	236	93	84 1	G	-	14.9
VA05036FCH	50	3600	326TS	1765	TEFC	60 2	237	124	90 0	204	236	92 4	84 1	G	-	3 32
VA05018FCH	50	1800	326T	1765	TEFC	62 5	237	124	90 0	204	236	93	84 1	G	-	5 78
VA05012FCH	50	1200	365T	1765	TEFC	61 7	237	124	90 0	204	236	93	84 1	G	-	17 8
VA06036FCH	60	3600	364TS	1765	TEFC	69 2	237	124	90 0	204	236	93	84 1	G	-	5 1
VA06018FCH	60	1800	364T	1765	TEFC	73 2	237	124	90 0	204	236	93 6	84 1	G	-	11 5
VA06012FCH	60	1200	404T	1765	TEFC	70 6	237	124	90 0	204	236	93 6	84 1	G	-	20 4
VA07536FCH	75	3600	365TS	1765	TEFC	85 3	237	124	90 0	204	236	93	84 1	G	-	6 14
VA07518FCH	75	1800	365T	1765	TEFC	89 5	237	124	90 0	204	236	94 1	84 1	G	-	13
VA07512FCH	75	1200	405T	1765	TEFC	87 8	237	124	90 0	204	236	93 6	84 1	G	79	23 4
VA10036FCH	100	3600	405TS	1765	TEFC	111	237	124	90 0	204	236	93 6	84 1	G	77	9 35
VA10018FCH	100	1800	405T	1765	TEFC	120	237	124	90.0	204	236	94.5	84 . 1	G	77	19
VA10012FCH	100	1200	444T	1765	TEFC	122	237	124	90 0	204	236	94 1	84 1	G	73	43 5
VB12536FCH	125	3600	444TS	1167	TEFC	144	81. 0	47 2	45	69 7	124	94 5	80 8	H	78	14 7
VB12518FCH	125	1800	444T	1781	TEFC	140	902	529	369	595	930	94 5	88 4	G	81	32 6
VB12512FCH	125	1200	445T	1185	TEFC	149	860	489	554	860	1303	94 1	83 3	F	76	50 7
VB15036FCH	150	3600	445TS	1167	TEFC	168	81. 0	47 2	45	69 7	124	94 5	80 8	H	83	16 8
VB15018FCH	150	1800	445T	1785	TEFC	170	1070	624	441	650	1120	95	86 8	G	84	38 3
VB15012FCHU	150	1200	445T	1186	TEFC	176	1085	609	664	1097	1628	95	84 1	G	80	55 2
VB15012FCH	150	1200	445TS	1186	TEFC	176	1085	609	664	1097	1628	95	84 1	G	80	55 2
VB20036FCH	200	3600	445TS	1167	TEFC	225	81. 0	47 2	45	69 7	124	95	80 8	H	88	20 4
VB20018FCHU	200	1800	445T	1784	TEFC	225	1440	824	589	965	1540	95	87 3	G	87	48
VB20012FCHU	200	1200	447T	1188	TEFC	230	1395	785	884	1295	2150	95	85 6	F	81	71 8
VB25036FCH	250	3600	447TS	3570	TEFC	278	1825	1126	368	600	1025	95	88 5	G	89	23 4
VB25018FCHU	250	1800	447T	1784	TEFC	279	1820	1037	736	1140	1900	95 4	87 9	G	88	60 5
VB25018FCH	250	1800	447TS	1784	TEFC	279	1820	1037	736	1140	1900	95 4	87 9	G	88	60 5
VB25012FCHU	250	1200	449T	1187	TEFC	280	1825	996	1105	1660	2800	95 4	87 4	G	81	93
VB30018FCH	300	1800	449TS	1783	TEFC	335	2115	1228	883	1309	2356	95 4	87 6	G	88	73 6
NOTE: Engineering Data is for estimating purposes only
