Alfa Laval – spiral heat exchangers The all-round heat transfer solution
Open the catalog to page 1Spiral-shaped heat exchangers are not a new idea – but Alfa Laval has perfected the design. Exceptional compactness and self-cleaning design make Alfa Laval spiral heat exchangers extremely versatile. Ideal for everything from dirty fluids to high vacuum condensation.
Open the catalog to page 2Product ranges We provide fixed-size and customized product ranges to meet the needs of our customers. Fixed-size ranges We make small units for general use, and for application-specific purposes such as the wastewater industry. Customized range To meet requirements for a range of sizes and specifications, the majority of the spiral heat exchangers we supply are individually customized. 4 Alfa Laval – spiral heat exchangers The idea of using spiral-shaped fluid channels for heat transfer arose in response to a particular customer’s process problem. Other technologies had failed, but in this...
Open the catalog to page 4Alfa Laval – spiral heat exchangers 5 Heat exchange duties that benefit from the strengths of spiral heat exchangers include: liquid/liquid heating, cooling or heat recovery, where one or both of the fluids may cause fouling. vapour/liquid condensing, particularly at very low pressure and/or highvolume flow. The design, shape and size of the spiral channels can be customized so that they are a perfect match for the demands associated with a wide range of process fluids, thermal duties and industrial applications. Strong on customized solutions The spiral heat exchanger is a very versatile...
Open the catalog to page 5Some customers choose spiral heat exchangers to boost the performance of their existing processes. Others use them for thermal duties in processes that would otherwise simply be impossible. Whether replacing existing “inefficient” technology or being used in revolutionary new applications, spiral heat exchangers are the first choice for processes that involve demanding liquid/liquid duties. The self-cleaning heat exchanger for demanding liquid/liquid duties Single channel technology makes keeping clean easier Single channel technology – what goes in must come out As the name indicates,...
Open the catalog to page 6Alfa Laval – spiral heat exchangers 7 Easy access When processes involve fluids that are capable of causing a high degree of fouling, it is important to have easy access to the inside of the heat exchanger for cleaning and inspection. Compared with other types of heat exchanger, spiral units provide the best access to their heat transfer area – with no special tools or lifting equipment required. Each fluid channel is easily accessed via its cover, exposing the whole of the heat transfer surface. Two covers enable one or two fouling fluids Both hot and cold channels are designed to...
Open the catalog to page 7One of the best examples of the flexibility of a spiral heat exchanger is its capability as a condenser. Different condensing duties place different demands on a heat exchanger. The desired condensing performance is achieved by determining the flow path of the vapour. Alfa Laval spiral condensers perfectly complement Alfa Laval’s other process condensers – the AlfaCond and the Compabloc – to provide customers with a full range of condensers for the entire range of their processes and applications. The customized condenser The versatility of spiral heat exchangers makes them ideal for...
Open the catalog to page 8Coolant Coolant Vapour from column Condensate Inert gas Two units in one – cross-flow and counter-current paths in the same unit The flexible flow-path arrangement and installation possibilities provided by spiral heat exchangers give them important advantages compared with other condensing solutions. Two heat exchange duties can be performed within a single spiral to further reduce capital equipment costs, and to maximize operating efficiency. For example, a spiral heat exchanger can act as a condenser and sub-cooler for condensate and/or inert gases, or as a pre-heater to remove...
Open the catalog to page 9Corporate Brochure 12 History, experience and expertise It takes experience to build the kind of expertise that provides answers The largest manufacturer of heat transfer equipment in the world Our worldwide sales and service representatives ensure that we can provide excellent local service to all prospective and existing customers, while also drawing on the wider experience and expertise accumulated within our global organization. This wealth of knowledge and experience is especially relevant to the spiral heat exchanger. Alfa Laval has been making spiral heat exchangers for more than...
Open the catalog to page 10Alfa Laval – spiral heat exchangers 11 Continual development Spiral heat exchangers are a wellestablished product, and have been around for a long time. Nevertheless, Alfa Laval heat exchangers are designed using the very latest techniques and testing methods. Our sales staff are equipped with sophisticated, state-of-the-art calculation and quotation tools. Our manufacturing and R&D departments are constantly working to make improvements on production techniques and component design – again drawing on the vast pool of skills and know-how available within Alfa Laval. Inspiration from our...
Open the catalog to page 11Minimum Maximum Area range per body 1 m2 700 m 2 10 ft 2 7000 ft 2 Design temperature -100 0C 4000C -150 0F 7500F Design pressure Full vacuum 40 barg and above 580 psig and above Pressure vessel codes PED, ASME, AS1210 and others Standard construction materials Stainless steel, carbon steel Other construction materials Any metal that can be cold formed and welded – including Duplex, titanium, Hastelloy, 904L Performance range 12 Alfa Laval – spiral heat exchangers Performance and applications
Open the catalog to page 12Typical applications Alfa Laval – spiral heat exchangers 13 Type of fluids and gases Fouling liquids – containing solids, fibres, liquors, slurries and sludges. Gases – pure vapour and mixtures with inert gases. Type of duty Liquid/liquid – preheating, heating, cooling, interchanging, heat recovery. Vapour/liquid – top condensers, reflux condensers, vacuum condensers, vent condensers, reboilers, gas coolers. Type of industry Petrochemical Refinery Steel making Pulp and paper Metal/ore processing Wastewater treatment Pharmaceutical Vegetable oil processing Distillery
