Solar Junior G - Dry coolers – commercial range - Alfa Laval - #2

Text version of the page

How to contact Alfa Laval Up-to-date Alfa Laval contact details for all countries are always available on our website at www.alfalaval.com ERC00137EN 0809 Alfa Laval reserves the right to change specification without prior notification. Dimensions & weights coil fans max. dimensions (mm) fixing points (mm) surface int. vol. weight size no. ø A B H C C1 C2 D m2 l kg 5 1 500 900 895 900 648 810 40.4 8 65 7 1 500 900 895 900 648 810 53.9 11 70 9 1 630 1125 1095 1000 873 1015 67.9 14 90 10 1 630 1125 1095 1000 873 1015 90.5 19 100 11 2 500 1575 895 900 1323 810 80.8 16 105 12 2 500 1575 895 900 1323 810 108 21 115 13 3 500 2250 895 900 1998 810 121 22 145 14 2 630 2025 895 1000 1773 1015 136 25 150 15 3 500 2250 895 900 1998 810 161 28 160 16 2 630 2025 1095 1000 1773 1015 181 33 170 17 3 630 2925 1095 1000 2673 1015 204 39 215 19 3 630 2925 1095 1000 2673 1015 271 50 245 20 4 630 3825 1095 1000 3572 1786 1786 1015 271 50 285 22 4 630 3825 1095 1000 3572 1786 1786 1015 362 64 320 27 5 630 4725 1095 1100 4473 1786 2687 1015 340 53 360 28 5 630 4725 1095 1100 4473 1786 2687 1015 453 70 400 29 6 630 5625 1095 1100 5373 2686 2687 1015 407 64 430 30 6 630 5625 1095 1100 5373 2686 2687 1015 543 85 480 Code description Benefits • Heavy duty coil & casing materials, resulting in a long operational product life. • Plain profile fins make the coil less prone to fouling and easier to clean. • Excellent sound characteristics • Reliable performance, Eurovent certified. • Easy-install & maintenance. • Energy efficient - low total cost of ownership. • One full year product guarantee. SJGE - 9 - 1 - 630 - 1400 - 3/400/50 - 7 - DN - Options Tube connection (DN=flange, R=outer thread) No. of circuits Power supply (3/400/50 or 1/230/50) Fan speed (700, 900, 1150 or 1400 rpm) Fan diameter (500 or 630 mm) No. of fans Coil size Special model SOLAR Junior dry cooler
