How to contact Alfa Laval Contact details for all countries are continually updated on our website. Please visit www.alfalaval.com to access the information direct. Alfa Laval in brief Alfa Laval is a leading global provider of specialized products and engineered solutions. Our equipment, systems and services are dedicated to helping customers to optimize the performance of their processes. Time and time again. We help our customers to heat, cool, separate and transport products such as oil, water, chemicals, beverages, foodstuff, starch and pharmaceuticals. Our worldwide organization works closely with customers in almost 100 countries to help them stay ahead. PPM00033EN 0609
Open the catalog to page 1Compabloc - compact performance Compabloc - the new laser welded heat exchanger series
Open the catalog to page 2more resistant to pressure peaks and cycling. This boosts the reliability and safety of the unit as well as providing better heat transfer performance. Flow paths The two media flow in alternately welded channels between the corrugated plates. They flow in a cross-flow arrangement within each pass (see figure at right) while the overall flow arrangement is counter-current for a multi-pass unit (see sectional view below). When required, the unit can be designed with overall co-current operation. Each pass is separated from the adjacent passes by a pressed baffle, Panel Heat transfer plate...
Open the catalog to page 3Compabloc plate heat exchanger installed for liquid-to-liquid heat recovery in a chemical plant in Scandinavia Cross-section of a baffle arrangement illustrating flow distribution Range CP (TIG welded , medium pressure, cleanable mechanically ):CP15 & CP20 CPL (laser welded , high pressure , cleanable chemically) :CPL30,CPL50 & CPL75 CPK (laser welded , medium pressure, cleanable mechanically):CPK40,CPK50 & CPK75 HCP (laser welded,hygienic design and manufacture) :HCP15 ,HCP20,HCP30& HCP40 CPM (laser welded, 2 section condenser with 2 different cooling media): CPM15,CPM20& CPM30 More in...
Open the catalog to page 4Flow configurations for different duties Compabloc can be designed with both single-pass or multi-pass flow configurations. For condensation and liquid-toliquid duties without temperature cross, the single-pass configuration is suitable with its total cross-flow. For duties with temperature cross and close temperature approaches, a multipass configuration is suitable. Each pass is in cross-flow, but the overall flow pattern within the heat exchanger is counter-current. The configuration of Compabloc has unique advantages that permit: • a different number of passes on the two circuits,...
Open the catalog to page 5Compabloc as pre-heater, condenser and reboiler column condenser reboiler pre-heater vapour non-condensable gases condensate vapour/liquid mixture liquid condensate steam Reboiler Two-pass process condenser with gas/liquid seperation • Compactness – takes only a fraction of the floor space of a shell-and-tube heat exchanger. Condensation & evaporation In condensing and evaporating duties, the Compabloc provides additional advantages: • Large cross-flow area and short flow path – fit low-pressure condensing duties and allow very low pressure drops. Designed with demanding duties in mind When...
Open the catalog to page 6Applications Oil & gas production • Heat recovery in TEG systems (gas dehydration) • Heat recovery, cooling, condensation & reboiling in amine systems (gas sweetening, sour service) • Heat recovery, heating and cooling in crude oil dehydration and desalination systems • Condensation in vapour recovery units • Heat recovery, cooling, condensation and reboiling in NGL fractionation systems Refineries Various condensing & reboiling duties such as: • Condensation of naphta in atmospheric distillation • Top condensing on fractionators in FCC, hydrocracking, H2S strippers, etc. • Propane & butane...
Open the catalog to page 7Compact facts about Compabloc Design temperature: up to 350°C (660° F), down to -100°C (-148° F). Design pressure: up to 35 barg (500 psig) depending on models and full vacuum (FV). Maximum heat transfer area: 320m2 (3 450 ft2). Maximum liquid flow rate per unit: 4 000m3/h (17 500 USgpm). Lowest achievable temperature difference: 3° C (5.4° F). Duty: heat recovery (feed/bottom on stripping/distillation column), cooling, heating, condensation, partial condensation, reboiling, evaporation and gas cooling. Performance: low to high thermal length or NTU duty. Handles any corrosive medium. In...
